1, Factory price
2, Quality gurrantee
3, Fast delivery
4, Low cost shipping
5, Samples available for evaluate
6, World class customers experience
Product Name: 40KV 3300PF 332 HV ceramic capacitor china supplier
High Voltage Ceramic Capacitor 40KV 3300PF, Molded type Ultra-high Voltage Ceramic Capacitors 40KVAC, 40KVrms 332 high voltage doorknob capacitor, UHV doorknob ceramic capacitor offered by AnXon Electronic
Rated Spec: |
40KV 3300PF , 40KV 332 |
AnXon P/N |
AXCHV40DL332KDB |
Tolerance: |
K, ±10% |
Type: |
Molded / Doorknob / Screw Mounting |
Ceramic Dielectric : |
N4700 |
Operating Temperature: |
-30C ~ 85C |
Size / Dimension(ΦD×T*H): |
D:60mm, H:38mm |
High Voltage Ceramic Capacitor 3.6KV, 6.5KV, 7.2KV, 10KV, 12KV, 13KV, 15KV, 20KV, 24KV, 25KV, 30KV, 35KV, 36KV, 40KV, 50KV, 60KV, 70KV, 80KV, 100KV, 120KV, 150KV Information:
- Rated Voltage (V): 3.6KVrms -70KVrms, 10KVdc-150KVdc
- Withstand Voltage: 6KVrms-50KVrms, 20KVdc-200KVdc
- Impulse Voltage: 45KVdc-225KVdc
- Capacitance Range: 10pF - 100000pF
- Operating frequency: 20KHZ-1000KHZ
- Materials: N4700, Y5T, Y5P, Y5V, Y5U
High voltage ceramic capacitor supplier, molded doorknob capacitor manufacturer,
More specifications
Part No. |
Rated Spec |
Testing voltage |
Partial discharge |
Dissipation factor |
Dimension(mm) |
||
kVdc |
kV/1min |
|
1kHz/1V |
D |
H |
M |
|
AXCHV40DL441KDB |
40KV 440PF |
DC60KV AC40KV |
AC20KV<8PC |
≤0.1% |
30 |
32 |
M4X6 |
AXCHV40DL561KDA |
40KV 560PF |
30 |
32 |
M4X6 |
|||
AXCHV40DL701KDB |
40KV 700PF |
38 |
36 |
M4X6 |
|||
AXCHV40DL132KDB |
40KV 1300PF |
40 |
36 |
M5X6 |
|||
AXCHV40DL152KDA |
40KV 1500PF |
52 |
36 |
M5X6 |
|||
AXCHV40DL172KDB |
40KV 1700PF |
52 |
36 |
M5X6 |
|||
AXCHV40DL202KDB |
40KV 2000PF |
52 |
30 |
M5X6 |
|||
AXCHV40DL202KDB |
40KV 2000PF |
58 |
36 |
M5X6 |
|||
AXCHV40DL332KDB |
40KV 3300PF |
60 |
38 |
M8X8 |
|||
AXCHV40DL402KDB |
40KV 4000PF |
70 |
38 |
M8X8 |
|||
AXCHV40DL452KDB |
40KV 4500PF |
70 |
38 |
M8X8 |
|||
AXCHV40DL502KDB |
40KV 5000PF |
80 |
38 |
M8X8 |
|||
AXCHV40DL552KDB |
40KV 5500PF |
80 |
38 |
M8X8 |
|||
AXCHV40DL802KDB |
40KV 8000PF |
106 |
38 |
M8X10 |
|||
AXCHV40DL103KDB |
40KV 10000PF |
98 |
150 |
M8X10 |
|||
AXCHV40DL203KDB |
40KV 20000PF |
98 |
225 |
M8X10 |
|||
HV Capacitor Application Guide
