A Traditional Vertical Rotor Mill,Suitable For Granulation,
Pulverising, Shredding, Chopping etc.
From Dry And Wet Materials
Direct Drive Multi Mill
Direct Drive Multi Mill is a self-contained portable unit that is widely used for milling, dispersing, shredding and breaking down of agglomerates into small size particles.
Multimill is widely used for wet and dry granulation, pulverization in pharmaceutical, chemicals etc. It operates on the principle of variable force swing beaters having both knife & impact edges rotating within a selected screen to get the required size reduction. A rotor assembly has 12 blades with knife/impact edge and 2 scrapper blades.
Material fed in the hopper passes down to the processing chamber where it moves to the periphery and passes through the screen radially and tangentially. Output depends on material characteristics, moisture content, fiber content, screen size, input particle size etc., but generally an output of 100 to 500 kg per hour can be optimally achieved.
The Machine is useful for high speed granulating, pulverising, shredding, chopping etc, a wide range of wet & dry materials without special attachments. It is also used for recovery of powder from half filled or rejected capsules.
The effective performance and high utility offered by these Direct Drive Multi Mills makes them the preferred choice across the pharmaceutical industries across the globe.
The Machine is driven by a 2.2 kw electric motor and is designed for continuous operation. Standard Direct Drive Multi Mill is belt driven with ‘Four Stage Step Pulley’ to select rotor speed of 720 / 1500 / 2100 / 3000 rpm. Reversing switch is provided to reverse direction of rotation of rotor. AC inverter drive can be provided for stepless speed variation.
Features:
- A Traditional Multi Mill suitable for pulverising, granulation, shredding, chopping etc. from dry and wet materials.
- Rotor, hopper, discharge bowl etc can be easily removed for cleaning.
- Rotor has 12 blades with blunt and knife edges for hammering and cutting action and is easy to remove.
- Speed is variable and reversible
- 300 mm diameter standard screen in required mesh size
- Mounted on a freely standing mobile platform castor for easy movement
- Different mounting structure of Direct Drive Multi Mill is available as per client’s requirement
- Output varying from 100 kg to 800 kg per hour depending on product & screen.
