Genew GM2204-CATV ONU ftth EPON modern Optical terminal integrated access device OLT ONT GPON CPE
ONU GM2204-CATV is an integrated access ONU of GM2000 series of EPON products. As a terminal access device of an access network, it can interconnect with GX3000 serial OLT via an optical splitter (ODN) and optical fiber to form a passive optical network access network system, and can also manage all ONU terminals via OLT. It provides 4 FE interfaces, 2 VoIP interfaces and 1 CATV interface, has compact structure and high integration level, and is convenient for maintenance and management. GM2204-CATV is suitable for being applied to FTTH access ways for three-in-one integrated access of broadband, voice and CATV of residence communities.
1 Achieve IEEE802.3ah standard
2 Provide 2-channel VoIP voice, 4-channel FE Ethernet and 1-channel CATV service and achieve three-in-one
3 Support SIP, MGCP and H. 248 protocol and flexible service configuration
4 Support flexible QoS setting and low time delay
5 Provide 4 FE Ethernet interfaces of RJ45 interface type and support self-adaptation of five kinds of straight and crossed network cables
6 Support IEEE 802.1Q VLAN function, with an uplink and downlink symmetric transmission rate of 1.25G
7 Support bidirectional bandwidth control, efficient multicast service and controllable multicast service (support IGMP snooping)
8 Support abundant OAM functions, and ONU automatic discovery and recognition function (plug and play)
9 Support abundant test and warning functions and achieve warning, performance statistics and traffic monitoring
10 Control based on service bandwidth and support dynamic bandwidth allocation (DBA)
11 Support ONU remote diagnosis and quick positioning of fault reasons
Packaging:
1. All products will be packed in carton, so the product can get effective protection to avoid damage.
2. Packaging according to customer requirement
Shipping:
1. We shipping via DHL / FedEx / TNT etc for samll orders. Yow can get your packages in about 3-5 days all over the world.
2. For big order, we will arrange Air cargo for your shipment, so it will be much cheaper than DHL, UPS etc.
3. You can choose your own shipping agent, we will provide good cooperation for it.
1,We can provide detail documents and remote help for device installation and configuration.
2,Warranty: 1 year. ( After the quality guarantee period began to charge appropriate maintenance service fee.)
3,Our company promises goods enjoy full return due to quality problem since goods delivered within 7 days or 15 days , returned goods must keep original state and it’s accessories are complete.
Genew Technologies Co., Ltd. designs, manufactures and sells telecommunications infrastructure, handsets and customer premise equipment and provide services associated with their installation, operation, and maintenance. Our portfolio also includes OEM/ODM services with world-class telecommunication partners such as Huawei, ZTE, Datang Mobile, UTStarcom, Nokia-Siemens Networks and Fiberhome.
While historically the vast majority of our sales have been to industrial clients involved in Mining, National Grid and Military in China, we have expanded our focus to build a global presence and currently sell our products in several other established and emerging growth markets, which include Japan, India, Latin America, EMEA and Asia.
