Help CenterWholesale P10 Outdoor Full Color LED Display Module
Related Products
-
China Supplier P8 SMD Waterproof Full Color LED Display ModuleUS$ 8.00 - 9.00MOQ: 300 Pieces -
Factory Price P6 Full Color Outdoor LED Screen Hire LED Screen ModuleUS$ 13.20 - 14.20MOQ: 300 Pieces
-
Outdoor Ph10 LED Display Module P10-1r Outdoor LED Display ModuleUS$ 4.00 - 5.00MOQ: 500 Pieces
-
P10 Outdoor White Color LED Display ModuleUS$ 4.90 - 5.50MOQ: 300 Pieces
-
Outdoor LED Display Modules 320*160 P10 Yellow Color LED ModulesUS$ 4.90 - 5.50MOQ: 300 Pieces
Outdoor ph10 LED Display Module,P10 LED Module;LED Display Panel,LED Board Display,Full Color LED Display,Outdoor LED Video Display,Sports LED Screen
P10 Outdoor Full Color LED Module
Description
1,High brightness even under sunlight,light weight by using die-casting aluminum cabinet;
2,Good waterproof IP65 for front and IP 54 for rear,anti-corrosion,andtifogging,long life span>10000 houhttp://jiacailed.en.china.cnrs;
3,High brightness up to 6300CD,long view distance from 100M away;
4,Made with high quality Epistar leds to keep high quality,low lighting decay,energy saving;
5,Brightness can be adjusted automatically according to different surrondings,can be set to open and close the screen on fixed auctomatically
6,Cabinet size and material can customized according different projects.
P10 LED Module Specification
Item |
Technical parameter |
|
|
Panel |
Dimension |
(W)320mm*160mm(H) |
Pixel pitch |
10mm |
|
Pixel Density |
10000dots/ M2 |
|
Pixel configuration |
1R1G1B |
|
LED specification |
SMD3535 |
|
Pixel resolution |
(W)32 dots*16dots(H) |
|
Average power |
10W |
|
Panel weight |
0.455KG |
|
|
Cabinet&Bracket
|
Cabinet size |
960mm*960mm |
Quantity of panel |
19.531PCS/M2 |
|
Best viewing angle |
H:>170 V:>120 |
|
Best viewing distance |
10-100M |
|
Working temperature |
-20-+65 |
|
Panel power supply |
5V40A |
|
Screen power supply |
AC220V—AC250V |
|
Max power |
700W/M2 |
|
Average power |
350W-500W/M2 |
|
|
Technical parameter |
Driving device |
16016 Constant current drive |
Drive type |
1/4 Scanning |
|
Refresh frequency |
240-1000HZ/S |
|
Display color |
4096*4096*4096 |
|
Brightness |
6500cd/ M2 |
|
Life span |
100000Hours |
|
Communication distance |
100M |
|
Packing & Shippment
1, Delivery time:For LED module 1-5days,for led display and rental led cabinet 5-12days after received of deposit.All our products proceeded aging test before shipment.
2,Packing: (1)carton (2) anti-shaking wooden box (3) flight case
Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM , any your customized led display we can help you to design and put into production.
3. Distributorship are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Successful & Win
Trade Terms
1. Payment: T/T, 40% deposits before production, 60% balance to be paid before shippment
2. Freight charges are quoted under your requests
3. Shipping port: Xiamen, China
4. Warranty time: 2years.If there is no manmade problems,we will repair for you freely.
Q:What’s your payment term?
A:The term’s of payment is 40% deposit,and balance T/T before shippment
Q: What about the quality?
A: We control the quality form the raw material, we only choose the qualified supplier to cooperate, and we have strictly inspection process, we know how to keep the brand value for both of us!
Q: Do you offer FREE sample?
A: We need to charge for the cost of the sample, however it can be refund if your place a lagre order.
Q: How many years of warranty can you offer?
A: We normally offer 1 year of warranty, but you need longer warranty, the price should be a little higher.
Q: What's the delivery time?
A: For module as normally within 7 working days and for screen and led cabinet the delivery date is 15-25 working days.
