P10 Outdoor Tri Color LED Display LED Sign Display
- 1000000 Square Meter / Square Meters per Month
- Xiamen
- 60W UL CE LED Canopy Lamp with aluminum frame Ex-factory price from Shenzhen
- 80W Energy-Saving Gas Station LED Canopy Lamp hot sale from Shenzhen
- 60W UL CE Energy Saving LED Canopy Lamp with 3 years warranty from Shenzhen
- 2014 new design, led flood light, led Gas Station Lamp, LED canopy light 100w
- Led flood light, led Gas Station Lamp, LED canopy light 100w
- 120W High power cree led canopy lamp Wholesale from Shenzhen for gas staton
Product Details
Place of Origin: | Fujian, China | Brand Name: | Jiacai | Model Number: | P10 |
Usage: | Outdoor | Tube Chip Color: | Other, Dual | Display Function: | Video |
Pixels: | 10mm | Screen Dimension: | Customized Size |
Product Description
Multi Color LED Display,LED Display Outdoor,Display LED,LED Screen Advertising,LED Scrolling Message Board,Digital Display Signs,Running LED Display,LED Display Board,LED Display Curtain,LED Sign Display
Multi Color LED Display Specification
Description | Technical parameter |
|
Specification | Module size | 320*160mm |
Pixel pitch | 10mm | |
Pixel density | 10,000dots/m2 | |
Pixel configuration | 1R1G | |
Pixel resolution | W:32dots*H:16dots | |
Cabinet Size | 960mm*960mm | |
Total weight | 45kg/sqm | |
Best viewing angle | 10-100m | |
Temperature | Storage: -30degree~+70degree | |
Working: -20degree~+50degree | ||
Operating ambient humidity | 10%--95% | |
MTBF | ≥10,000hours | |
Life span | ≥100,000hours | |
Flatness | Tolerance of interpixel ≤0.3mm | |
Tolerance of modules clearance≤0.6mm | ||
Power switch | Automatic switch | |
Horizontal viewing angle | 120degree | |
Vertical viewing angle | 110degree | |
Warranty time | 1years | |
Control method | Synchronization or asynchronization |
Description
1 . DIP led encapsulation confirm the high brightness even under sunlight
2.Good waterproof IP65 for front and IP54 for rear,anti-corrosion,antifogging,long life span>100000Hours
3.Made with high quality Epistar leds keep high quality, low lighting decay, energy saving
4.Led display can show various advertising information including characters and letters, pictures, etc.
5. You can set several different display areas to achieve different visual display effects.
8. With automatic on/off software and intelligent brightness control, the product is energy and power saving.
9. The product supports USB drive character storing function and serial port 232 computer sending function.
10. Led display screen supports wireless, USB and RS232/485.
11. Led display screen supports synchronization with the display and of image and sound.
12. The software is easy to learn and we provide on-line free training service.
13. The hardware is convenient to assemble. The module design is suitable for different product sizes and satisfies various assembly demands.
Packing & Shippment
1, Delivery time:For LED module 1-5days,for led display and rental led cabinet 5-12days after received of deposit.All our products proceeded aging test before shipment.
2,Packing: (1)carton (2) anti-shaking wooden box (3) flight case
Our service
1. Your inquiry related to our products or price will be replied in 24hrs
2. OEM&ODM , any your customized led display we can help you to design and put into production.
3. Distributorship are offered for your unique design and some our current models
4. Protection of your sales area, ideas of design and all your private information
5. Top quality+Reasonable price+Responsible After Service=Successful & Win
Trade Terms
1. Payment: T/T, 40% deposits before production, 60% balance to be paid before shippment
2. Freight charges are quoted under your requests
3. Shipping port: Xiamen, China
4. Warranty time: 1years.If there is no manmade problems,we will repair for you freely.
Q:What’s your payment term?
A:The term’s of payment is 40% deposit,and balance T/T before shippment
Q: What about the quality?
A: We control the quality form the raw material, we only choose the qualified supplier to cooperate, and we have strictly inspection process, we know how to keep the brand value for both of us!
Q: Do you offer FREE sample?
A: We need to charge for the cost of the sample, however it can be refund if your place a lagre order.
Q: How many years of warranty can you offer?
A: We normally offer 1 year of warranty, but you need longer warranty, the price should be a little higher.
Q: What's the delivery time?
A: For module as normally within 7 working days and for screen and led cabinet the delivery date is 15-25 working days.
