Help CenterHT-M50 Lamp Pump Laser Marker
Related Products
Specifications
fiber laser marking system is a small size and high light beam quality,high speed Clear markThe lamp pump YAG series laser marker uses America high speed scanning galvanometer, British ceramic focus cavity and America laser rod, featuring high scanning precision, high speed and stable performance. It can satisfy the requirement of long time continuous work and carve metal and nonmetal materials. It is widely used in electronics, bearing, clock and watch, glasses, communication, electric apparatus, automobile parts, plastic keys, hardware tools, medical instruments, etc.
Carve metal and nonmetal materials; more suitable for circumstances that require super fine and high precision.
It is applied to electronic components, integrated circuit (IC), electric apparatus, mobile communication, hardware products, tool fittings, precision instrument, glasses, watch and clock, jewelry, automobile parts, plastic keys, construction materials, PVC pipes, medical instruments, etc.
Suitable materials include: common metal and alloy (all metals include iron, copper, aluminum, magnesium and zinc), rare metal and alloy (gold, nickel, and titanium), metal oxide, special surface process (phosphating, aluminum anodizing and electroplated surface), ABS material (electric apparatus shell, daily necessities), ink (light-transmitting keys, printing products), epoxy resin (packages and insulating layer of electronic components).
Model |
HT-M50 |
Laser wavelength |
1064nm |
Laser repeating frequency |
≤50KHz |
Maximum laser power |
50W |
Standard carving range |
100mm×100mm |
Optional carving range |
50mm×50mm/150mm×150mm (optional) |
Carving depth |
<1mm |
Carving line speed |
≤7000mm/s |
Minimum line width |
0.015mm |
Minimum character |
0.3mm |
Repeating precision |
±0.003mm |
Power supply |
220V/Single-phase/50Hz/30A |
Maximum integrity power |
5KW |
Dimensions (L*W*H) (mm) | |
Optics system (mm) |
1200*420*1180 |
Cooling system (split) (mm) |
Indoor: 280*300*700; outdoor: 880*300*700 |
Control system (mm) |
600*600*800 |
