Latest products in market hot sale,JKR40 newest automatic clay brick making machine with high quality
JKR series compact double stage mud brick making machine is composed of mixing part,extruding part,and vacuum system.
The above mixing stage is to add and mix raw material;the lower stage is for conveying,squeezing,extruding; The two stage using same one motor to work, such extruder is called Compact double stage vacuum extruder.To ensure the extruder working properly, the raw material must be sent to extruder’s mixing part continuously and evenly.If raw material is sent too much at one time, the vacuum chamber may be blocked.
The theory of vacuum extruder is ,once soil is sent to vacuum chamber,the air in the soil will be escaped at low pressure,using vacuum pump to absorb air into Atmosphere.Degassed soil would be collected and extruded again, then coming out from extruder mouth.The vacuum pump takes air and moisture out of soil, so the soil brick is with better shape and compact.Advantages of JKR40 clay brick making machine:
1.Strong applicability, lower energy consumption, only use one motor.
2.The raw material for making bricks can be clay, coal gangue.
3.It can produce solid,multi-holes and hollow bricks.
TECHNICAL PARAMETERS FOR JKR SERIES CLAY BRICK MAKING MACHINE:
| Model |
Throughput (Piece/hr) |
Power(KW) |
Exterior Dimension L×W×H (mm) |
Forming moisture content(%) |
| JKR30/30-2.0 | 5000~7000 | 55 | 3800x1200x1280 | 18~20 |
| JKR35/35-2.0 | 7000-9000 | 75 | 4700×1590×1680 | 18~20 |
| JKR40/40-2.5 | 8000-10000 | 90 | 4880×1690×1750 | 18~20 |
| JKR45/45-3.0 | 10000-13000 | 110 | 5880×1760×1870 | 16~20 |
| JKR50/50-4.0 | 13000-15000 | 160 | 5560×1780×1980 | 14~20 |
Note: The above capacity is based on Chinese brick size : 240X115X53 mm, if your brick size is different from our brick size, then the capacity will differ .We would send different brick capacity list and different brick machine price list to you once we get your mail to us.
The following is part of brick sample which clay brick making machine can produce .
Note: We can provide other different brick mould with different mould sizes according to your requirements.
JKR40 clay brick making machine production line:
Note:The above production line is based on soft clay,mud,soil.If your material is shale,fly ash,coal Gangue,or with big stones,grass roots,etc,or you want to buy brick carrying cars or robot ,brick stacker, the above line will be adjusted after we get your feedback for your material condition.
| After brick cutting how to do brick drying and firing | |||||||||||
| Item | Drying method | Firing method | Advantage and disadvantage | ||||||||
| 1 | Natural drying | Buyer Local kiln | Very low investment, but may take more labors | ||||||||
| 2 | Natural drying | Hoffman kiln | A little high investment, but may take more labors | ||||||||
| 3 | Natural drying | Tunnel kiln | High investment, but takes less labors than Item 2 | ||||||||
| 4 | Small tunnel dryer | Hoffman kiln | High investment, but takes less labors than Item 2 | ||||||||
| 5 | Small tunnel dryer | Tunnel kiln | Higher investment, but takes less labors than Item 4 | ||||||||
| 6 | Big Tunnel dryer | Tunnel kiln | Highest investment, but takes least labors | ||||||||
The same type of vacuum brick extruder does not necessarily produce a variety of brick,that depends on
the brick machine type and the size of the brick
2.What’s the difference between Vacuum extruder and non-vacuum extruder?
>>Vacuum brick extruder can make three kinds of brick:solid brick, porous brick and hollow bricks. To produce
different kinds of bricks by changing the different brick die.
>>Another type is the common clay brick machine, non vacuum brick extruder, can only produce solid bricks.
Vacuum brick is extruded out of the vacuum extruder. And non-vacuum extruder has no extraction equipment,
so the brick hardness is lower than vacuum brick.
>>The vacuum brick machine is first extracted with air and water and then fired, the production time and firing time
is shorter, rapid prototyping.Greatly reducing the production cycle time.
3.What types of brick machine can you produce production company?
Our company produces non-vacuum brick extruder, single-stage vacuum brick extruder, compact two-stage
vacuum brick extruder, split two-stage vacuum extruder. Customers can choose according to their own needs.
You can download our brick machine details and price list on our website:
4.How much calories for sintering a brick?
Generally, every 1 kg of calcined product, needs to consume about 1088 ~ 1388 kJ of energy
5.What percentage of water contained in the brick can be sintered?
Less than 8% of dry brick can be sintered, if the water moisture is too large, the brick will be easy to crack at
the sintering time.
6.If the soil contains stone, such soil can be used to make bricks?
No,the stone must be removed, otherwise the machine will accelerate wear and tear, or even damage to the
machine. Generally based on the size of stone, you can choose the following machines: stone removing roller
machine, roller sieve, thrust sieve.
Workshop for JKR40 clay brick making machine:
Yingfeng supply the following clay brick making machine and brick making equipment,you can choose what you need:
1. Belt type box feeder
2. Roller crusher, jaw crusher , hammer crusher
3. Double shaft mixer, double shaft mixer and extruder
4. Brick vacuum extruder, vacuum brick making machine
5. Automatic brick cutter system
6. Bricks separation machine
7. belt conveyor
8. Brick dryer
9. Brick tunnel kil
10. Brick kiln equipment
11. Automatic brick loading and unloading machine
12. Automatic brick packaging machine
13. Automatuc robot brick setting machine
14. Auotmatic brick stacking machine
15. Brick dryer and tunnel kiln design and construcion
16. Technical provide and technical supervision
17. Turn-key project
18. Full automatic brick project clay floor tile making machine
21. Full automatic clay brick making machine and brick making equipment
Clay brick making machine delivery for our clients :
1.Each small part of machine would be packed well, also we would arrange engineer to check each machine parts before delivery, so we can ensure buyer can get complete clay brick machine parts.
2. Some parts will be given soft protection before feeding in the container to make sure all the machine will be new when arriving at customer hand.
3. Inside the container, we will fix the machine with steel wire,to make sure all the machine will be fixed safety.
We have sold auto clay brick machine to more than 30 countries,like
Our clay brick making machine delivery photos for our clients:
Our Running brick production video link for your reference
( Please adjust the video image quality to 240 or 360P when watching)
JZ300 Non-vacuum clay brick producing line:
/watch?v=sjg7GsfcYfk
JKR30 Vacuum clay brick production line with brick separator:
/watch?v=TBgEnsWOGyM
JKRL35 Vacuum brick production line with unloader and brick loading cars:
/watch?v=IQtzh_pjcxA&feature=youtu.be
JKR40 Vacuum Clay block making machine:
http://youtu.be/jZmoW49xtF8 http://youtu.be/qOCe79N43ns
JKRL45 Vacuum Clay brick production line with auto brick loading cars:
http://youtu.be/3DCR2rR_wYA
JZK50 Vacuum Clay brick producing line with dryer and hoffman kiln:
http://youtu.be/h-m4Vnq8v3c
JKY60 Auto brick production line with tunnel kiln and dryer:
/watch?v=8R_XzKkDySU&feature=youtu.be
Yingfeng Automatic brick stacking machine
/watch?v=r45s8057XGY
Contact us:
China Mobile Number ( Whatsapp, Wechat ,Viber): 0086 18638712391 or 008615039963315
Email: kai(at) skype: fanchen588
Web:
How to visit us or check clay brick making machine quality
If you want to visit our Chinese factory, please note our city name, Zhengzhou city.
Our air port name is : Zhengzhou Xinzheng International air port.
Train station name is: Zhengzhou (Zhengzhou north) train station
If you do not want to fly far away to China ,you can also visit our brick plant in your local places :
