Rotating Unions and Rotary Joints (also known as rotary swivels, rotary couplings) are precision mechanical devices used to transfer fluid from a stationary source, such as a supply pipe, into a rotating piece of machinery. Rotating Unions and Rotary Joints are used in numerous manufacturing processes to cool, heat, or transfer fluid (pneumatic or hydraulic) power.
Rotary Joints and Rotary Unions allow the feed through of water, glycol, air, hydraulic, coolant, MQL, hot oil, steam, vacuum and a variety of other media. Rotary Joints and Rotary Unions that can be configured for installation at the end of a shaft or around-the-shaft.
Deublin Rotating Union 5/8"-18 Machined RH 17-025-012
- Monoflow design
- Self-supported rotating union
- Steel rotor nickel-plated
- Special bearing
- Aluminum housing
| Hose Connection | NPT | |
|---|---|---|
| Housing Connection | Radial | |
| Housing Hose Thread Size B | 1/4" | |
| Media | Air, Hydraulic, Vacuum | |
| Passages | One Passage | |
| Rotor Description | 5/8"-18 Machined RH | |
| Rotor Thread Direction | RH | |
| Rotor Thread Size A | 5/8"-18 | |
| Rotor Type | Threaded | |
| Seal Combination | Standard Seals | |
| Union Size | 1/4" |
| A Rotor Thread | 5/8"-18 | |
|---|---|---|
| B Port | 1/4" | |
| C | 38 MM | |
| D | 83 MM | |
| E | 29 MM | |
| F | 16 MM | |
| G | 8 MM | |
| H | 22 MM | |
| J | 39 MM |
| Air Pressure | 10 BAR | |
|---|---|---|
| Air Temp | 121 C | |
| Hydraulic Pressure | 207 BAR | |
| Hydraulic Temp | 121 C | |
| Max Speed | 250 /MIN | |
| Vacuum Pressure | 94.82 kPa | |
| Vacuum Temp | 121 C |
Company Name: Suzhou Benign Intelligent Equipment Co., Ltd.
Operational Address: 204A, Bldg. A, Founder Tech Park, No. 188, Suhong East Road, Suzhou, Jiangsu, China (Mainland)
Website: https://img13.fr-trading.com
Contact Mr. Benign Chen
Department: Director/CEO/General Manager
Job Title: General Manager
Telephone: 86-0512-62890289
Mobile Phone: 18020285375
Fax: 86-0512-62890289
Zip: 215000
Thick Carton Box
Small Size(2-4 pcs per box) |
35mm*20mm*20mm |
Medium Size( 5-10 pcs per box) |
45mm*30mm*25mm |
Large Size( more than 10pcs per box) |
60mm*40mm*25mm |
Shipping
EMS, TNT, UPS, FEDEX Courier for small quantity.
Ocean transport for large quantity.
Warranty: 1 year from the day of shipment.
