Rotating Unions and Rotary Joints (also known as rotary swivels, rotary couplings) are precision mechanical devices used to transfer fluid from a stationary source, such as a supply pipe, into a rotating piece of machinery. Rotating Unions and Rotary Joints are used in numerous manufacturing processes to cool, heat, or transfer fluid (pneumatic or hydraulic) power.
Rotary Joints and Rotary Unions allow the feed through of water, glycol, air, hydraulic, coolant, MQL, hot oil, steam, vacuum and a variety of other media. Rotary Joints and Rotary Unions that can be configured for installation at the end of a shaft or around-the-shaft.
Deublin Rotating Union 1 1/4" NPT RH 527-000-001007
- Duoflow design
- Self-supported rotating union
- Radial housing connection
- Balanced mechanical seal
- Keyed rotor seal
- Easy and quick replacement of sealing components (rotor seal, floating seal)
- Ball bearings lubricated for life
- For poor water quality (E.L.S.)
- 3 vent holes
- Forged brass housing
- Stainless steel rotor
-
Special options: threaded vent holes
Seal Combination - Standard - Standard: Carbon Graphite/Silicon Carbide
- E.L.S.: Silicon Carbide/Silicon Carbide for severe conditions (poor water quality)
| Duo Flow Elbow Type | Fixed Supply Pipe | |
|---|---|---|
| Elbow Hose Thread Size O | 3/4" | |
| Fixed Supply Thread | NPT | |
| Fixed Supply Thread Size | 1/2" | |
| Hose Connection | NPT | |
| Housing Connection | Radial | |
| Housing Hose Thread Size B | 1 1/4" | |
| Media | Water, Water Glycol | |
| Passages | Two Passages | |
| Rotor Description | 1 1/4" NPT RH | |
| Rotor Thread Direction | RH | |
| Rotor Thread Size A | 1 1/4" | |
| Rotor Type | Threaded | |
| Seal Combination | Standard Seals | |
| Union Size | 1 1/4" |
| A Rotor Thread | 1 1/4" | |
|---|---|---|
| B Port | 1 1/4" | |
| C | 90 MM | |
| D2 | 238 MM | |
| E | 56 MM | |
| F | 29 MM | |
| G | 32 MM | |
| H | 46 MM | |
| J | 133 MM | |
| K-NPT | 1" | |
| M | 35 MM | |
| N | 71 MM | |
| O Port | 3/4" | |
| R | 207 MM |
| Max Speed | 1500 /MIN | |
|---|---|---|
| Torque Rating | 2.03 Nm | |
| Water Glycol Pressure | 10 BAR | |
| Water Glycol Temp | 93 C | |
| Water Pressure | 10 BAR | |
| Water Temp | 93 C |
