Product Details
Type: | Other, Hour Meter | Size: | 52mm | Car Make: | Industrial and commercial vehicles |
OE NO.: | MTM | Place of Origin: | American Samoa | Brand Name: | CURTIS |
Model Number: | enGage II 300R | Warranty: | 2 Years |
Product Description
CAN and Serial Communication instruments from Curtis display vehicle data and fault information. These gauges connect directly to Curtis controllers and I/O modules, easily, seamlessly and conveniently.
The Curtis enGage® II is a dual function, microprocessor based instrument that can be factory or user defined to monitor various functions including fuel, temperature, pressure, voltage, battery state of charge and maintenance/status.
enGage® II
LCD Style | Fixed Segment (Monochrome Only). |
Housing | Round |
Display | TN LCD, Fixed Segment, Monochrome |
Serial | No |
CANbus | CANopen, J1939 |
Analog In | 0 |
Digital In | 0 |
Outputs (MOSFET) | 0 |
VCL | No |
LEDs | 1 |
Push-Buttons | 2 (optional) |
Video-Input | No |
Audible Alarm | No |
Real-Time-Clock | No |
Connector | AMP |
Programmer Emulation | No |
Curtis Model enGage® II 300R is ideal for use in industrial and commercial vehicles including: material handling, outdoor power and construction equipment, engine driven stationary devices, commercial cleaning equipment, golf/lighton-road and other mobility aids. Also ideally suited for monitoring scheduled maintenance, warranty and leasing intervals.
• Multiple functions in one programmable unit:
– Lower overall stocking requirements.
– Reduced installation time and labor.
– Reduced vehicle instrumentation count.
– Ease of ordering.
– Volume pricing/purchasing advantages.
• Field programmable maintenance monitor allows dealers and/or users to program maintenance intervals for their
specific application.
• Optional settable hour meter allows replacement of a failed hour meter without loss of total elapsed time.
• Flexible output modes include flashing LCD segments, panel mounted LED and FET (0.5A) which allows the equipment designer to define critical parameters and to choose appropriate notification methods, such as alarms or buzzers.
• True Curtis battery monitoring technology means proven algorithm protection capabilities providing reliable state of charge information.
• Sealed front panel buttons allow easy:
– Setting of maintenance interval.
– Setting of battery monitoring profile.
– Re-setting of maintenance hours.
– Setting of total hour meter (optional).
• Clock function allows vehicle operator easy and safe access to time of day status.
• Mounting bracket and integrated connector lowers installation and production costs and eliminates traditional mounting
hardware kits.
• EEPROM non-volatile memory retains usage data without battery back-up.
• Aesthetically attractive contemporary look enhances vehicle styling and maximizes readability. Overlays can easily be customized to create a specific brand/logo identity.
• Reliable, all solid state design means no moving parts minimizing warranty costs.
• Over 40 years of Curtis instrumentation design and manufacturing experience insures products are both innovative and extremely reliable.
• Curtis global network of sales and technical support provides timely and complete applications support.
• Operating Voltages
12VDC nominal (9 to 15VDC)
12-48VDC nominal (9 to 60VDC)
• Operating Temperature
- 40°C to + 85 °C
• Storage Temperature
-50 °C to +90 °C
• Humidity
95% RH (non-condensing) at +38 °C
• Shock
SAE J 1378 March 83.
Amplitude 44-55 g, half sine,
9-13 ms duration
• Vibration
SAE J 1378
Double amplitude of 1.53mm with
frequency sweep for 10-80-10 Hz
(20 g max) at 1 minute intervals
• Sealing: FACE REAR
Molex connector - IP65 IP40
AMP connector - IP65 IP65 (with connector
installed)
• Output signal format (Power MOSFET):
N channel MOSFET (switches ground side only)
Programmable; capable of sinking up to 0.5A, maximum
• Adjustable BDI Discharge Profile Range:
Full: 1.80 – 2.30 V/cell (Factory set at 2.04 V/cell)
Empty: 1.50 – 2.20 V/cell (Factory set at 1.73 V/cell)
100 mV/cell is minimum differential between full & empty
• BDI Open Circuit Reset Level factory set at 2.09 V/cell
• Maximum Current Ratings:
12VDC Only Models: 35 mA @ 15VDC
12 – 48VDC Models: 35 mA @ 60VDC
NOTE: BDI, Maintenance Monitor, Settable Hour Meter and Time of Day functions require programming buttons on front display.
Buttons NOT available on units rated 12VDC only.
