The Curtis 700 Series are highly reliable solid state hour meters and counters that offer an unprecedented combination of patented technology, performance, reliability and value.
MODEL 700: 2-Wire Hour Meter, displays only when powered. Available in AC/DC.
MODEL 701: 3-Wire Hour Meter, has a provision or continuous display. Available in AC/DC and DC-only.
MODEL 703: Pulse Counter. Available in AC/DC and DC-only.
700 Series
| nput Voltage Range (Nominal) | 5 - 100 VDC, 100 - 230 VAC |
| Mounting | Panel |
| Display | LCD, 6-Digits |
| Number of Hour Meters | 1 |
| Factory Programmable Service Intervals | No |
A wide variety of industrial and commercial applications, including scheduled maintenance, warranty and leasing – for medical equipment, transport and industrial vehicles and other industrial equipment.
• All-8’s LCD function test: each digit displays an eight for one
second after power-up.
• Attractive 6-digit LCD 5mm or 7mm high digits (7mm with
optional backlighting) are much easier to read than electromechanical
meters, which have only 3mm high digits.
• Silent operation – no moving parts. Eliminates annoying
gear and motor noise.
• Exceptional reliability due to nonvolatile memory (EEPROM)
which retains data for 25+ years.
• Wide voltage ranges, for example, one unit can be powered
from 75 to 270 VAC anywhere between 48 and 440 Hz –
ideal for distribution and worldwide markets without having
to stock multiple model types.
• Electrical reset (optional).
• Available in ten case styles – all fit in standard hour meter/
counter cutouts.
• Multiple mountings available – Metal U-bracket, “U” clamp/
stud (D, Q, R and S cases), flange mount with hardware (F,
T, G, J cases), or mounting clip (G, L, Y, Z, cases).
• Backlit units allow external illumination control, i.e., on/off
or dimmer (12VDC only).
• Flashing hourglass icon indicates when the hour meter is
accumulating time.
• Memory will arm only when power has been applied for five
seconds (with no loss of time or counts).
• Low power consumption.
• UL and CE recognized.
NOTES:
1. Mating connector must be installed.
2. Equivalent to Delphi-Packard connector P/N 12162000 2-pin.
3. Equivalent to Delphi-Packard connector P/N 15336035 4-pin.
4. Equivalent to Molex connector P/N 43045–0412.
5. UL files AU1841 and E45175.
6. R(5mm) and Q housings also available in a 65/65 version
(see model encodement).
7. F= 1/4”, T= 3/16”
