Curtis offers the widest range of Battery State-of-Charge (BSOC) instruments in the industry and continues to develop new algorithms to improve accuracy as well methods of measuring the state-of-charge of other battery chemistries and alternative fuel sources.
Curtis Model 803 combines in one instrument a completely solid state battery discharge indicator, an LCD hour meter and lift lockout, housed in a 52mm case. Void of moving parts, this combination instrument is exceptionally reliable even in severe operating environments.
803
| Function | BDI / Hour Meter. |
| Lift Lockout | Yes |
| Display | Tri-Color, 10-bar LED |
| Hour Meter | Yes |
| Output | 1 Amp Relay |
| Mounting | U-bracket |
| Interconnect | Molex Connector |
| Low "Fuel" Warning | Two LED Bars Flash Alternately |
| Adjustable | Yes |
| Housing | 52 mm round |
| Keyswitch Input | Yes |
| BDI Reset Method | CTR, OCR |
| Operating Voltage [VDC] | 12 - 80 |
Curtis Model 803 is a combination gauge ideally suited for electrically powered vehicles.
‘Fuel’ Gauge Features
• Multicolor 10-bar LED displays state of charge (5 green,
3 yellow, 2 red LEDs).
• Flashing red LED signals “energy reserve” alarm at
70% discharged.
• Double flashing red LEDs signal “empty” alarm at
80% discharged.
• Normally closed relay opens at 80% discharge for lift lockout.
This unique holding relay will only lock out at the end of a
lift cycle.
• Recognizes improperly charged battery.
• Keyswitch activated LED display (Fuel gauge electronics are
energized as long as they remain connected to the battery).
• Wide range adjustable discharge profile.
• Dual reset methods in each gauge: Open Circuit Reset for
vehicles that exchange batteries and Charge Tracking Reset
for vehicles whose batteries remain connected to the gauge
during recharge.
Hour Meter Features
• Monitors use-time throughout the equipment’s lifespan.
• Records and displays up to 99,999.9 hours on its LCD, rolls
over and continues to count and display.
• Hour meter LCD remains on as long as battery is connected.
• Stores latest total in EEPROM nonvolatile memory, without
need of power.
• Operates and displays in temperatures from –40°C to +65°C
under harsh conditions of vibration, shock, moisture and dust.
System Voltages
Available in single voltages from 12 VDC to 80 VDC, or in dual
voltage of 24/36, 36/48, 24/48 or 72/80 VDC. Operating
range is ± 25% of nominal voltage.
• Hour meter accuracy: +0.1%
• Operating Temperature:
–40°C to +65°C
• Shock & Vibration:
Meets SAE J 1378
• Humidity:
95% RH (non-condensing) at +38°C
• LCD Character Height:
5 mm
• Mating Connector:
Molex 8 pin, 39-01-2085
• Discharge Range:
Empty from 1.57 volts/cell to1.93 volts/cell.
• Reset Levels:
Open circuit reset (OCR)at 2.09 volts/cell.
Charge Tracking Reset (CTR) tracks battery recharge at 2.35 volts/cell full and 2.10 volts/cell empty.
Company Name: Suzhou Benign Intelligent Equipment Co., Ltd.
Operational Address: 204A, Bldg. A, Founder Tech Park, No. 188, Suhong East Road, Suzhou, Jiangsu, China (Mainland)
Website:
Website on :http://benign.en.
Contact Mr. Benign Chen
Department: Director/CEO/General Manager
Job Title: General Manager
Telephone: 86-0512-62890289
Mobile Phone: 18020285375
Fax: 86-0512-62890289
Zip: 215000
Warranty: Two year limited warranty from time of delivery.
