1000mW 2T2R MIMO 2.4GHZ 300Mbps Wireless WIFI Oem Ceiling AP

US$ 1 - 90 MOQ: 5 Pieces

Key Specifications

Place of Origin:

China

Brand Name:

JDL

Model Number:

AP305

Longyan JDL Technology Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen. hongkong. xiamen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name JDL

Model Number AP305

Product Features

- Compact ceiling-mount design with optimized RF performance

- 535Mhz AR9341 RF Chipset, 802.11b/g/n Support

- 64MB SDRAM + 8MB Flash Build-in for Higher Performance

- Gateway / Repeater / AP / Wireless ISP Client operation modes

- IEEE 802.3af PoE supports up to 60 meter (180 feet) deployment

- Central AP Control Management Software Support

Wireless
Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Data Rate	300Mbps
Frequency Band	2.4~2.4835GHz
Wireless Transmit Power	11n MCS7:26±1dBm,11g 54Mbps:26±1dBm,11b 11Mbps:27±1dBm
Receive Sensitivity	11N MCS0@-83dBm ; MCS7@-65dBm,11G 54Mbps@-82dBm ; 6Mbps@-95dBm,11B 11Mbps@-85dBm ; 1Mbps@-95dBm
Operation Mode	Gateway, Repeater(Extender), AP(access point), Wireless ISP Client
Wireless Security	64/128-bit WEP, WPA/WPA2, WPA /WPA2-Personal (TKIP/AES)
System Requirements	Windows 7/Vista/XP/2000,Mac OS®, Linux or Android OS, iOS
Hardware
Interfaces	2 x RJ-45 for 10/100 Mbps(POE),1 x Power DC Jack
MCU	AR9341
SDRAM&FLASH	64MB+8MB
Button	1 x Reset button(Reset & Factory Defaults)
LED indicator	WiFi, Power, System
Antenna	2x built-in 5dBi omni-directional Antenna
Power Supply	IEEE 802.3AF 48V/12V1A;110V/220V
Software
Wireless Function	Distance Control (802.1x Ack timeout),Multiple SSID (4 SSID)
Security	WEP Encryption-64/128/152 bit,WPA/WPA2 Personal (WPA-PSK using TKIP or AES) WPA/WPA2 Enterprise (WPA-EAP using TKIP),Hide SSID,MAC/IP Address &URL filtering Wireless STA (Client) connected list
DHCP	DHCP Server, DHCP Client
Network	Port Mapping, DMZ Host, Statics Routing, DDNS,UPNP
