1800mhz wireless transmitter 33dBm-43dBm,90-95db 1,Good quality guarantee
2,Excellent workmanship
3,OEM,ODM services
Kingtone Repeaters system is designed to solve problems of weak mobile signal, which is much cheaper than adding a new Base Station (BTS). Main operation of RF Repeaters system is to receive low power signal from BTS via radio frequency transmission and then transmit the amplified signal to the areas where network coverage is inadequate. And the mobile signal is also amplified and transmitted to the BTS via the opposite direction.
1800mhz wireless transmitter 33dBm-43dBm,90-95db Function:
1,Donor Unit,Remote Unit;
2,In-band and out-band can be customized;
3,The Remote unit can be used out of the BTS coverage;
4,Highly selective channel selector can process 1 or 2 or 4 or 4 or 8 channels simultaneously
5,Easy to install on wall or pole
1800mhz wireless transmitter 33dBm-43dBm,90-95db Applications:
To expand signal coverage of signal blind areas where signal is weak or unavailable.
Outdoor: Airports, Tourism Regions, Golf Courses, Tunnels, Factories, Mining Districts, Villages etc.
Indoor: Hotels, Exhibition Centers, Basements, Shopping Malls, Offices, Packing Lots etc.
1800mhz wireless transmitter 33dBm-43dBm,90-95db Technical Specification:
Schematic Diagram of outdoor coverage solution:
Schematic Diagram of In-Building Coverage Solution:
GSM Wireless transmitter and receiver GSM 900
Specification of gsm 1800 repeater :
Type |
KT-DSRC*1800mhz wireless repeater |
||||
Frequency |
UL:1710~1735MHz DL:1805~1830MHz UL:1735~1755MHz DL:1830~1850MHz |
||||
Output Power |
33dBm |
37dBm |
40dBm |
43dBm |
|
Gain |
90-95dB |
||||
Gain Adjust Range |
≥30dB;1dB/step |
||||
AGC Range |
≥25dB |
||||
IMD3 |
≤-50dBc |
≤-45dBc |
|||
Noise Figure |
≤5dB |
||||
Ripple in Band |
≤3dB |
||||
Time Delay |
≤10μs |
||||
EVM |
≤12.5%(RMS) |
||||
PCDE |
≤-35 dB |
||||
ACRR |
fc-5MHz |
≤-45dBc/30KHz |
|||
fc+5MHz |
≤-45dBc/30KHz |
||||
fc-10MHz |
≤-50dBc/30KHz |
||||
fc+10MHz |
≤-50dBc/30KHz |
||||
Spectrum mask |
Meet ETSI specification |
||||
Spurious Emission |
9KHz-1GHz:≤-36dBm/30KHz;1GHz-12.75GHz:≤-30dBm/30KHz |
||||
Port Impedance |
50Ω |
||||
VSWR |
≤1.5 |
||||
Monitoring Mode |
Local;Remote(Optional) |
||||
Power Supply |
AC220V(Normal); AC110V or DC48V or Solar Powered(Optional) |
||||
Power consumption |
130W |
190W |
240W |
300W |
|
Mechanical Specifications
Weight |
25kg |
25kg |
35kg |
35kg |
Dimension |
590*370*250 mm |
670*420*210 mm |
||
Installation mode |
Wall installation (normal);Pole installation(optional) |
|||
Connector |
RF:N female; Optical:FC/APC |
|||
Environment Specifications
Case |
IP65(Slave) |
Temperature |
-25~+55°C(Slave) 0°C~+55°C(Master) |
Humidity |
5%~95% (Slave) |
1800mhz wireless transmitter 33dBm-43dBm,90-95db Pictures :
Frequency range list for our repeaters :
Support System |
Frequency Range |
Output Power |
GSM900MHZ |
890-915MHz/935-960MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
DCS1800MHz |
1710-1785MHz/1805-1880MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
PCS1900MHz |
1895-1910MHz/1975-1990MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
GSM850MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA450MHz |
450-457.5MHz/460-467.5MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA800MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA1900MHz |
1880-1890MHz/1960-1970MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
UMTS850MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
UMTS2100MHz |
1920-1980MHz/2110-2170MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
GSM900/1800MHZ |
890-915MHz/935-960MHz 1710-1785MHz/1805-1880MHz |
2W/5W/10W/20W/ |
GSM850/1900MHZ |
824-849MHz/869-894MHz 1880-1890MHz/1960-1970MHz |
2W/5W/10W/20W |
GSM900/UMTS2100 |
890-915MHz/935-960MHz 1920-1980MHz/2110-2170MHz |
2W/5W/10W/20W/ |
Our repeater support above frequency range .
Our present manufacturing service:
1. Single-band repeaters of LTE/GSM/CDMA/PCS/DCS/WCDMA
2. Dual-band repeater of GSM/DCS; GSM/WCDMA; CDMA/PCS;
3. Tri-band repeater of GSM/DCS/WCDMA
4,Trunk Amplifier
5. All kind of Antenna/Splitter/Connector/Cable
Question: I work in an office building where my cell phone coverage in certain areas, including my office, is non-existent or spotty at best. How can I improve my coverage?
Answer: The requirement for reliable, always-on cell phone coverage within the office environment is increasing dramatically. It is not unusual to encounter trouble spots within a building where cell phone signals are weak or non-existent.
Kingtone repeater provides affordable and clear coverage to those trouble spots. The unit can be easily deployed and provides a coverage range of up to 100,000 square feet. Multiple units can be easily deployed to cover office areas and working locations.
Kingtone repeater can be deployed even without access to the roof or outside.
Welcome to OEM /ODM For more infomaion about our repeater and antennas,Refer to our Website:
Support System |
Frequency Range |
Output Power |
GSM900MHZ |
890-915MHz/935-960MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
DCS1800MHz |
1710-1785MHz/1805-1880MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
PCS1900MHz |
1895-1910MHz/1975-1990MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
GSM850MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA450MHz |
450-457.5MHz/460-467.5MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA800MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
CDMA1900MHz |
1880-1890MHz/1960-1970MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
UMTS850MHz |
824-849MHz/869-894MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
UMTS2100MHz |
1920-1980MHz/2110-2170MHz |
2W/5W/10W/20W/30W/40W/50W/60W |
GSM900/1800MHZ |
890-915MHz/935-960MHz 1710-1785MHz/1805-1880MHz |
2W/5W/10W/20W/ |
GSM850/1900MHZ |
824-849MHz/869-894MHz 1880-1890MHz/1960-1970MHz |
2W/5W/10W/20W |
GSM900/UMTS2100 |
890-915MHz/935-960MHz 1920-1980MHz/2110-2170MHz |
2W/5W/10W/20W/ |
Question: I work in an office building where my cell phone coverage in certain areas, including my office, is non-existent or spotty at best. How can I improve my coverage?
Answer: The requirement for reliable, always-on cell phone coverage within the office environment is increasing dramatically. It is not unusual to encounter trouble spots within a building where cell phone signals are weak or non-existent.
Kingtone repeater provides affordable and clear coverage to those trouble spots. The unit can be easily deployed and provides a coverage range of up to 100,000 square feet. Multiple units can be easily deployed to cover office areas and working locations.
Kingtone repeater can be deployed even without access to the roof or outside.
Question: I frequently work from my home office, but my cell phone doesn't.
Answer: A cell phone is critical when you work at home, because it provides a ready link to the office and customers – without giving out your home number. But even in urban areas, hills or buildings often block wireless signals.
Kingtone repeater can be easily deployed to provide coverage throughout your house. In a home, the donor unit is generally deployed outside – for example, under the eaves. Because it is more sensitive than your phone and is mounted higher up, it can usually detect signals that your phone can't. The coverage range of 15,000 to 50,000 square feet (2,000 to 4,600 square metres) is adequate for most homes.
Question: I live in a rural area. Rather than having a second phone line for work, I'd like to use my cell phone, but it only works outside.
Answer: Signals in many rural areas are marginal and cannot penetrate the walls of your home. Kingtone repeater can be easily deployed to provide coverage throughout your house. In a home, the donor unit is generally deployed outside – for example, under the eaves. Because it is more sensitive than your phone and is mounted higher up, it can usually detect signals that your phone can't. The coverage range of 15,000 to 50,000 square feet (2,000 to 4,600 square metres) is adequate for most homes.
Question: When I'm at the cottage, I'd like to stay in touch, but if I publish my cottage number, everyone will call. I'd like to just use my cell phone. Can you help?
Answer: Signals in many cottage areas are marginal and cannot penetrate the walls of your cottage. Kingtone repeater can be easily deployed to provide coverage throughout your cottage. In a cottage, the donor unit is generally deployed outside – for example, under the eaves or on a utility pole. Because it is more sensitive than your phone and is mounted higher up, it can usually detect signals that your phone can't. The coverage range of 15,000 to 50,000 square feet (2,000 to 4,600 square metres) is adequate for most cottages.
You get the privacy of your cottage and the convenience of your cell phone. Just remember to turn it off sometimes!
Question: I'm a production manager in a factory, and no cell phones work inside. I spend most of my time in a couple of spots. Can you help?
Answer: Factories and warehouses with lots of metal construction often have poor signals. While these buildings may be large, the employees are generally located in only a few areas.
Kingtone repeater can be easily deployed to provide coverage in those spots. The donor unit is deployed on the roof and connected to a coverage unit inside. The coverage range of up to 100,000 square feet is adequate for most trouble spots. Multiple units can be easily deployed to cover office areas and other working locations.
