- hottest poe wireless outdoor repeater
Overview:
CPE008 is a 5.8Ghz IEEE 802.1 n outdoor wireless AP, accord with standard of 802.11 n wireless transmission, and downward compatible with 802.11 b/g. 802.11 n standard is 802.11 b/g wireless transmission standard three times higher data transfer rate, It can reach 60Mbps. Outstanding performance,Cost-effective, high data throughput, CPE008 is the best solution for outdoor wireless transmission, especially in video surveillance applications. CPE008 with high output power and high receiver sensitivity, and can extend the network coverage, and provide for 1 - 5 km transmission distance. High throughput of 802.11 n wireless transmission standards to reduce roaming between AP and provide stable and reliable wireless connection. CPE008 meet IP55 waterproof outdoor installation standards, support - 20 ~ 70 ° C wide working temperature range, ease of installation at the scene of the harsh environment. Through feed-horn and twisted-pair 12 VDC power supply for equipment. Advanced network management functions (including STP spanning tree storm) prevent the loop. QoS (WMM) can provide different priority for different applications. The IGMP snooping support multicast filtering, WEP, WPA, WPA2, MAC address filtering. SNMP v3 improve system security. CPE008 integrating the excellence of wireless transmission technology and the advanced network management function, make it become the outdoor wireless AP solution high-performance high reliability products, suitable for most wireless network environment.
Features and discriptions:
1.5.8Ghz outdoor CPE
2.800mW ,300Mbps
3.Gate way, bridge, wireless ISP
4.2KM signal coverage
5.14 DBI antenna
Specification:
Specification |
||||
Hardware |
||||
MCU |
AR9344 |
|||
RF |
AR9344 |
|||
Memory |
64MB DDR RAM |
|||
Flash |
8MB(May extend to 16MB) |
|||
2 x RJ-45 for 10/100 Mbps |
||||
Interface |
1 x Reset button(reset & factory defaults) |
|||
1 x Power DC Jack |
||||
Power |
12V/1A DC Jack or 24V/1A Passive POE |
|||
RF |
||||
Frequency |
802.11a/n: |
|||
5.180 GHz ~ 5.850 GHz |
||||
Modulation |
OFDM/BPSK/QPSK/CCK/DQPSK/DBPSK |
|||
Throughput |
300 Mbps |
|||
802.11n HT40(5.8GHz) |
802.11n HT20(5.8GHz) |
802.11a |
||
Sensitivity |
-83dBm @ MCS0 |
-86dBm @ MCS0 |
- 89dBm @ 6Mbps |
|
-65dBm @ MCS7 |
-68dBm @ MCS7 |
- 73dBm @ 54Mbps |
||
Radio1(WLAN1) |
||||
802.11n(5.8GHz)(± 1.5dBm) |
802.11n(5.8GHz)(± 1.5dBm) |
802.11a(± 1.5dBm) |
||
HT40 @ MCS0~2/MCS8~10 |
HT20 @ MCS0~2/MCS8~10 |
26.5dBm @ 6~24Mbps |
||
Output Power |
26.0dBm @ MCS3/MCS11 |
26.5dBm @ MCS3/MCS11 |
26dBm @ 36Mbps |
|
25.5dBm @ MCS4/MCS12 |
26.0dBm @ MCS4/MCS12 |
26dBm @ 48Mbps |
||
25.0dBm @ MCS5/MCS13 |
25.5dBm @ MCS5/MCS13 |
25dBm @ 54Mbps |
||
24.5dBm @ MCS6/MCS14 |
25.0dBm @ MCS6/MCS14 |
|||
24.0dBm @ MCS7/MCS15 |
24.5dBm @ MCS7/MCS15 |
|||
Antenna |
Internal 14dBi directional ANT(Horizontal Beamwidth: 60º/Vertical Beamwidth: 25º) |
|||
System monitoring |
Status in hand , useful statistic and Event log |
Logs |
Supports local logs,logs host,logs file export |
Reset |
Renew system or restore to factory defaults |
Backup |
Restore settings & configuration of the device to local file |
Temperature |
Working: -10°C~55°C |
|
Storage: -20°C to 70°C |
||
Humidity |
5%~95%( typical) |
|
Waterproof |
IP65 |
|
Dimension |
||
Height |
||
