SYCWM5-1600(B+C) Full Servo Motor Driving Mechanical Hand

SYCWM5-1600(B+C) Full Servo Motor Driving Mechanical Hand thumbnail-1
SYCWM5-1600(B+C) Full Servo Motor Driving Mechanical Hand photo-1
US$ 3,000 - 50,000 MOQ: 2 Sets
Key Specifications
Get Latest Price
Condition:
New
Elevation Speed:
8s
Vertical Travel(mm):
1600mm
Contact Supplier Request Quote Chat Now
Jinan Qifan International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao / Beijing/ Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Elevation Speed 8s
Vertical Travel(mm) 1600mm
Horizonal Travel(mm) 2500
Application Other, Pick and put
Place of Origin Shandong, China
Brand Name SHENYU
Model Number SYCWM5-1600
Power(W) 4500W
Certification CE,SGS
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

SYCWM5-1600(B+C) Full servo motor driving robot:



Features:

Full servo horizontal large series manipulator arm used for 400--4000 tons of various plastic injection molding machine,AC servo drive for 5 axis.Finished product arm to take out the product and runner,up and down the arm struture is double cut type;Takeout time of 1.5 sec,the cycle time of all 12 sec,the biggest load of 100 kg(including finished products ang fixture).Applied to quickly remove or out a variety of applications,especially the long shape prooducts such as car bumpers,door trim and insert the embedded applications.



Specifications:

Model Unit SYCWM5-1600(B+C)
Type   Telescopic type
Moulding machine size ton 360-1200
Vertical stroke mm 1600
Crosswise stroke mm 1000
Traverse stroke mm 2500
B-axis angle ° 270.
C-axis angle ° 179
Max load(Includes gripper) Kg 20
Minimun take time Sec 8.
Dry cycle time(without gripper) Sec 35
Drive mode   Full servo
Working air pressure Kgf/cm² 6
Power consumption KW 4.5
Power   AC200±10%(50/60Hz)



Machine warranty and after-sale service:

1. Machine warranty is 12 months, broken parts free change during the time.

2. 24 hours technical support by email or calling.

3. Friendly English user manual in video and book.



Our factory:

SYCWM5-1600(B+C) Full servo motor driving mechanical hand

SYCWM5-1600(B+C) Full servo motor driving mechanical hand





SYCWM5-1600(B+C) Full servo motor driving mechanical hand





To know more information about our machine, please don't hesitate to contact us:

SYCWM5-1600(B+C) Full servo motor driving mechanical hand
