500kg MF Induction Melting Furnace

Name: 500kg MF Induction Melting Furnace
Brand: Xinxing
SKU: 102512791
Availability: InStock

Xinxing Casting Technology Development Department

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Other, Induction Furnace, Induction Melting Furnace

Usage:

Melting Furnace

Payment & Shipping

Payment Methods:

Port of Shipment:

Jiangmen China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, Induction Furnace, Induction Melting Furnace

Usage Melting Furnace

Place of Origin Guangdong, China

Brand Name Xinxing

Model Number KGPS-0.5t

Warranty 12 months

After-sales Service Provided Engineers available to service machinery overseas

500kg MF induction melting furnace

Advantages

Machine Features:

1. Turn on and turn off the smelter easily, and power failure will not affect the service life of electric furnace.

2. Adopt constant power to control the circuit, maintain constant power while melting, and keep faster melting rate.

3. Set up over voltage, over current and water deficient protector, and run safely.

4. The motherboard adopts CAD technology, integrated circuit board, low-fault-rate, easy-manipulating, effortless maintenance.

5. Zero voltage starts up softly, high initial power, don´t impact on the electric network.

6. Apply to melting ferrous metal and non-ferrous metal like copper, aluminum, zinc, steel, iron, stainless steel etc..

Technical Parameter:

Factor		Technical parameter
General parameter	Rated capacity	500KG
	Time consumption per stove	Approx 65-70min
	working noise	<85db(out of 1M)
	Furnace structure	Aluminum/SS/ Steel outer shell
Electrical parameter	Rated power	350KW
	Rated frequency	1.0KHZ
	Input voltage	380,440V
	Output voltage	750V
	Adaptive transformer	≥350KV
	Power supply start power	100%
Cooling water system	Inlet water pressure	0.2-0.3Mpa
	Inlet water temperature	40°C
	Outlet water temperature	≤55°C
