Offer 180*180*60 Xindafan Air Cooling Fan

Offer 180*180*60 Xindafan Air Cooling Fan thumbnail-1
Offer 180*180*60 Xindafan Air Cooling Fan photo-1
US$ 4.05 - 4.85 MOQ: 480 Pieces
Key Specifications
Get Latest Price
Electric Current Type:
AC
Mounting:
Other, air cooling fan
Blade Material:
Plastic
Contact Supplier Request Quote Chat Now
Deqing Xinda Electric Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Electric Current Type AC
Mounting Other, air cooling fan
Blade Material Plastic
Place of Origin Zhejiang, China
Brand Name XINDAFAN
Model Number XD18060
Voltage 220
Power 0.32/0.22
Air Volume 290/330
Speed 2350/2500
Certification CE

Offer 180*180*60 xindafan air cooling fan

1.Housing:Aluminum alloy
2.Size:180*180*60mm
3.Blade:PBT Engineering Plastics
4.Insulating aterial centigrade :10MΩ at 500VDC between lead and frame
5.Inner press:1 min at 1500VAC/50-60HZ ,current<5mA
6.Working temperature:-20ºC~80ºC
7.Working humidity :20%~85%
8.Working  pressure:85V~125V for 110V and 190V~250V for 220V
9.Normal temperature working time: ball bearing hour's five,oil bearing hour's three.
10.Packing:10PCS/CTN
11.MEAS:42*40.5*23cm
12.G.W:16kgs    N.W:15kgs

Model
XD18060AC

Freq
Hz

Voltage
VAC

Bearing
Style

Current
AMP

Power
Watts

Speed
RPM

Airflow
CFM

Pressure
mmH2O

Noise
dBA

Weight

P/N

XD18060A1HSL

 50/60 110 S 0.62/0.44 72/50 2300/2500 290/330 15/17 57/59 1600g

XD18060A1HBL

 50/60 110 B 0.62/0.44 72/50 2350/2500 290/330 15/17 57/59

XD18060A2HSL

 50/60 220 S 0.32/0.22 72/50 2300/2500 290/330 15/17 57/59

XXD18060A2HBL

 50/60 220 B 0.32/0.22 72/50 2350/2500 290/330 15/17 57/59
S Sleeve bearing, B Ball bearing For the terminal connect version, change L in the Model to T



Offer 180*180*60 xindafan air cooling fan

Conversion Table of Airflow

CFM

m3/sec

m3/min

ft3/sec

2118

1

60

35.31

35.31

0.01666

1

0.5885

60

0.02832

1.69833

1

1

0.00047

0.02832

0.01666

Conversion Table of Air Pressure

mmH2O

inH2O

Pa=N/m

afm

1

0.03939

9.80665

0.00009

25.4

1

249

0.00246

0.10197

0.0040

1

0.00001

10332

407.1

101325

1


The data of regular product in picture is for your reference only, please refer to the data of actual product, we can make any model custom made.
