Home > Manufacturing & Processing Machinery > Metallurgy Machinery > Z9606A Semi-automatic Sand Core Shooter Machine Concrete Core Cutting Machine
Z9606A Semi-automatic Sand Core Shooter Machine Concrete Core Cutting Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Xinxing
Model Number:
Z9604A/Z9606A
Payment & Shipping
Payment Methods:
Port of Shipment:
Jiangmen China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Core Shooting Machine (at User's Site) Resin Sand Core Casting MachineNegotiableMOQ: 1 Set -
High Efficiency Full-automatic Sand Core Shooting MachineNegotiableMOQ: 1 Set
-
Import Components Shell Core Shooter MachineNegotiableMOQ: 1 Set
-
Core Making MachineNegotiableMOQ: 1 Set
-
Z863D-T Full-auto Core Shooter Faucet Mold Core ShooterNegotiableMOQ: 1 Set
Place of Origin
China
Brand Name
Xinxing
Model Number
Z9604A/Z9606A
After-sales Service Provided
Engineers available to service machinery overseas
Z9606A Core Shooter Machine
1. Application:
This machine is mainly used to make the solid sand cores, vertical parted type, single action dies
2. Main technical parameter:
Item |
Parameters |
Max. mould size |
600×600mm |
Max. weight of sand core |
15Kg |
Stroke of mould closing cylinder |
350mm |
Opening size of pattern plate |
1300mm |
Max. heating power of the sand box |
20KW |
Compressed air pressure |
0.5~0.6Mpa |
Total air consumption |
0.3 m3/ per sand shooting |
Power source |
AC3 380V 50HZ |
Sand hopper capacity(Extra large type) |
200 Kg |
