Epoxy Resin Automated Dispensing Machines With Single Liquid Dispensing
Automobile mechanical parts coating , cell phone buttons
point glue , mobile phone battery packaging,laptop
battery packaging , the coil point glue , PCB bonding / sealing ,
IC bonding / sealing , horn external punctuate glue , PDA
sealing , LCD sealing , IC packaging , casing bonding , optical
device processing , mechanical sealing , ink clip , LED , DVD ,
digital cameras , switches , connectors , radiators , semiconductor
and other electronics , clocks , toys , medical equipment , etc .
Dispensing Machine Applied glue or liquid
Silica gel , EMI conductive adhesive , UV glue , AG glue ,Fast dry glue , epoxy adhesive , sealant , hot glue ,grease , silver glue , red glue , solder paste , cooling paste ,prevent solder paste , transparent lacquer ,screw fixation agent, epoxy resin , instant glue , thermal compound , anti-solder paste , paint , etc .
Automatic glue dispensing machine main uses
1) Processing with bonding, infusion, coating, sealing, filling , drop , linear / arc / round gluing , etc .
2) Dispense in point , line , surface , arc , circle and irregular curve , and triaxial linkage function is available .
Specification for desktop automatic glue dispenser
Dispenser Robot Specification | |
Working area X/Y/Z(mm) | 400/400/100 |
Load Y Axis / Z Axis | 10kg / 5kg |
Program Display | Teach Pendant LCD |
Programming Method | Teach Pendant |
Power Supply | AC90~260V320W |
Working Temperature | 0~40°c |
Working Relative Humidity | 20~90% no condensation |
Dimensions(W x D x H) | 585 x 610 x 610 |
X&Y/Z(mm/sec) | 0.1~800/500 |
Resolution | 0.01mm / Axis |
Repetitive Positioning Accuracy | ±0.01mm/Axis |
Program Capacity | Min 100 group, 4000points/group |
Data Storage Type | CF Card |
Motion Control | PTP(Point to Point) & CP(Continuous Path) |
Motor System | Micro Stepping motor |
Interpolation Function | 3 Axis(Suit for 3D requirement) |
I/O Signals Port | 8 Inputs / 8 Outputs |
Robot Weight (kg) | 41kg |
If the adhsive 's package is 300G or 330G , we can recommend the machine wiht
our accessories , please check the attached picture, it is for your reference.
If the adhsive 's package is 20KG /bucket or others weight, according to your
adhesive package , we can recommend the machine wiht our accessories ,
please check the attached picture, It is for your reference.
If it is normol packing, you can choose ourstandard
machine. please check the attached picture,
it is for your reference.
Note :
The picture we attached is just for your reference. if you need to our machine, we can recommend you according to your requirement , different requirement , we will give your different solutions.
Best way is that Y&D robot can be used together with Y&D all accessories. it is good for your using.
