Specifications
Belt band conveyor,band conveyor,conveyor:1,big capacity50-600t/h
2,angle-iron/u-bar frame
3,hot in China,Peru mining,quarry
Belt band conveyor,band conveyor,conveyor:
Belt band conveyor description:
Our rubber belt conveyor characterizes big measure, simple structure, and convenient repairment, standard parts. It is extensively used in mine, metallurgy, coal and such industry to convey loose materials or finished products. According to the requirement of travelling craft, it can work solo and ally several machines together to form a horizontal or slant system. The rubber belt conveyor can be used in the atmosphere of temperature between -20-40 centigrade degree, and the temperature of materials need to be less than 50 centigrade degree.
Belt band conveyor parameters:
Width B(mm) |
500 |
650 |
800 |
1000 |
1200 |
1400(1600) |
||||||||||||||
Edge height H(mm) |
80 |
120 |
160 |
80 |
120 |
160 |
120 |
160 |
200 |
160 |
200 |
240 |
200 |
240 |
300 |
200 |
240 |
300 |
400 |
|
Diaphragm plate height (mm) |
75 |
110 |
150 |
75 |
110 |
150 |
110 |
150 |
180 |
150 |
180 |
220 |
180 |
220 |
280 |
180 |
220 |
280 |
360 |
|
Speed V(m/s) |
0.8 1.0 1.25 1.6 2.0 2.5 3.15 4.0 |
|||||||||||||||||||
Drum diameter (mm) |
400,500 |
400,500,630 |
500,630,800 |
630,800,1000 |
630,800,1000,1250 |
800,1000,1250,1400 |
||||||||||||||
Veer Drum diameter (mm) |
400 |
400,500 |
400,500,630 |
500,630,800 |
500,630,800,1000 |
630,800,1000,1250 |
||||||||||||||
Roller (mm) |
Φ89 |
Φ108 |
||||||||||||||||||
Normal angle |
0-30° 30° 40° 45° 50° 55° 60° 65° 70° 75° 80° 85° 90° |
|||||||||||||||||||
Angle range |
0-90° |
|||||||||||||||||||
Transmission |
Type I |
Motorized pulley(with brake) |
||||||||||||||||||
Efficacy KW |
1.5-7.5 |
1.5-11 |
1.5-37 |
1.5-90 |
1.5-110 |
|||||||||||||||
Type II |
Y motor +V belt + axis redactor(with brake)+driving drum |
|||||||||||||||||||
Efficacy KW |
3-11 |
3-15 |
3-22 |
|||||||||||||||||
Type III |
Motor +coupling + redactor + driving drum(with brake)(By a single motor drive) |
|||||||||||||||||||
Efficacy KW |
1.5-30 |
1.5-55 |
2.2-90 |
4-110 |
5.5-185 |
|||||||||||||||
