6061 Aluminum alloy square tube
| Material | 6063,6060,6061,6005 |
| Temper | T4,T5,T6 |
| Surface treatment | Mill Finish,Anodized,Powder Coated,Eletropharesis,Wooden Finish,Polish |
| Colour | Mill Finish,Anodized,Powder Coated,Eletropharesis,Wooden Finish,Polish |
| Length | as required |
| Fabrication | cutting,drilling,punching,milling,deburring,clearing,etc |
| Payment terms | TT or LC at sight |
| Package | inner plastic paper interleaving each piece tube,outer fixed by plywood or pallets,or as required |
| Delivery time | 7-15 days after order confirmation |
| Certification | ISO 9001:2008;ISO14001:2004;SGS |
| Capacity | 5000 tons per month |
Primary Technical Data
1)Chemical composition
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Zn |
Ti |
Impurity |
Al |
6061 |
0.4-0.8 |
0.7 |
0.15-0.4 |
0.15 |
0.8-1.2 |
0.04-0.35 |
0.25 |
0.15 |
0.15 |
Rest |
6063 |
0.2-0.6 |
0.35 |
0.1 |
0.1 |
0.45-0.9 |
0.1 |
0.1 |
0.1 |
0.15 |
Rest |
6060 |
0.3-0.6 |
0.1-0.3 |
0.1 |
0.1 |
0.35-0.6 |
- |
0.15 |
0.1 |
0.15 |
Rest |
6005 |
0.6-0.9 |
0.35 |
0.1 |
0.1 |
0.40-0.6 |
0.1 |
0.1 |
0.1 |
0.15 |
Rest |
2)Mechanical property
Alloy |
Temper |
Tensile strength |
Yield strength |
Elongation |
6061 |
T6 |
≥ 265Mpa |
≥ 245Mpa |
≥ 8% |
6063 |
T5 |
≥ 160Mpa |
≥ 110Mpa |
≥ 8% |
T6 |
≥ 205Mpa |
≥ 180Mpa |
≥ 8% |
3)Anodized
Grade |
Anodizing thickness |
Hole scaling quality of oxide layer |
|
Average thickness |
Local thickness |
P. Cr acid-erosion weight less method |
|
AA10 |
≥10um |
≥8um |
≤30 mg/d m2 |
AA15 |
≥15um |
≥12um |
|
4)Powder coating & wooden-grained
Coating thickness |
Coating impress rigidity |
Adhesive force of coating layer |
40-120um |
Indentation hardness>80 |
0 grade |
Our advantages
1)Engineering design and support.
2)Deep process:cutting,punching,drilling,milling,and fabricating.
3)High Quality system, strictly inspection during production and whole inspection before package.
4)Good performance, product warranty for 25 years.
Packaging Details: Products are well packed and clear labeled according to the regulations and customer's requests.
Delivery Detail: according to the quantity ,usually 15-25days after order.
