Ningbo Tractor With John Deere Chassis Tractor, 20hp to 55hp With 2WD and 4WD, Square Hood Tractor With Options

Main technical specifications

Model

HW204

HW254

HW304

HW354

HW404

Type

4×4 WD

Dimensions

of tractor

(mm)

Length(without ballast and linkage)

2950

3000

3150

Width

1530

1530

1550

Height (to exhaust)

1970

1970

1980

Height (to Cabin Top)

2250

Tread

Front Wheel

1200 (optional 1000, 1300)

Rear Wheel

1200 (optional 1000, 1300)

Wheel base

1450

Min. Ground Clearance

277

Min. Radius of

Turning(m)

One-side braking

2.4

No braking

2.8

Dry Mass(kg)

1300

Engine

Model

JD295IT

JD2100IT/

LD385

LD3T30/

LD390

LD4L22BT

LD4L23BT

Type

Vertical, Water Cooled and 4-stroke

Rated Power(KW)

14.7

18.4

22.1

25.7

29.4

Fuel

Diesel

Fuel consumption (g/kW.h)

≤250

≤248

≤238

≤238

≤245

Rated Rev.(r/min)

2400

Walking & turning

System

Tire

Front tire

6.00-16

Rear tire

9.5-24(optional 8.3-24,11.2-24)

Connection between engine and clutch

Shaft connection

Clutch

Single Disc, Dry-Friction, Single Stage

Transmission Box

(4+1)×2 Mechanical Type

Steering

Mechanical or Hydraulic Type

Suspension Type

Post positioned Tri-point Suspension, Catalogue I

PTO

Type and Rev.(r/min)

Single speed non-independent type 720 or double speed Non-independent 540/1000

Spline Size(mm)

Post positioned I35 Rectangle Spline with 6 teeth(6×28.91×34.79×8.69)
