Specifications
Middle series tractor from 30hp to 60hp,with multi-cyinders powerful engine,
2WD or 4WD,
many kinds options
Main technical specifications | ||||||||
Model |
TN280 |
TN350 |
TN400 |
TN450 |
TN500 |
TN550 |
||
Type |
4×2 WD |
|||||||
|
Dimensions of tractor(mm)
|
Length |
3150 |
3600 |
|||||
Width |
1550 |
1600 |
||||||
Height( to exhaust top ) |
1980 |
2200 |
||||||
|
Tread
|
Front Wheel |
1200 (optional 1000, 1300) |
1300 |
|||||
Rear Wheel |
1200 (optional 1000, 1300) |
1300 |
||||||
Wheel base |
1450 |
1950 |
||||||
Min. Ground Clearance |
277 |
325 |
||||||
|
Min. Radius of Turning(m) |
One-side braking |
3.1 |
3.4 |
|||||
No braking |
3.5 |
4.0 |
||||||
Dry Mass(kg) |
1300 |
1800 |
||||||
|
Engine
|
Model |
SL2105 |
LD4L22 |
LD4L23 |
JD495 |
XC498 |
XC/SL4105 |
|
Type |
Vertical, Water Cooled and 4-stroke |
|||||||
Rated Power(KW) |
20.6kw |
25.7kw |
29.4kw |
33.08 kw |
36.7kw |
40.4kw |
||
Fuel |
Diesel fuel |
|||||||
Fuel consumption (g/kW.h) |
≤250 |
≤248 |
≤238 |
≤238 |
≤245 |
≤245 |
||
Rated Rev.(r/min) |
2400 |
|||||||
|
Walking & turning System
|
Tire
|
Front tire |
6.5-16 |
6.5-16(optional 7.5-16,8.3-20) |
||||
Rear tire |
11.2-24 |
11.2-24 (optional 11.2-28,12.4-28) |
||||||
Connection between engine and clutch |
Shaft connection
|
|||||||
Clutch |
Single Disc, Dry-Friction, Single Stage |
|||||||
Transmission Box |
(4+1)×2 Mechanical Type |
|||||||
Steering |
Mechanical or Hydraulic Type |
|||||||
Suspension Type |
Post positioned Tri-point Suspension, Catalogue I,II |
|||||||
|
PTO
|
Type and Rev.(r/min) |
Single speed non-independent type 720 or double speed Non-independent 540/1000 |
||||||
Spline Size(mm) |
Post positioned I35 Rectangle Spline with 6 teeth(6×28.91×34.79×8.69) |
|||||||
Q. I'm a complete tractor rookie, never driven one in my life - can you help me?
A. Absolutely! Your new tractor comes with a training DVD and instruction manual. If you still need assistance, we're only a phone call away - we're here to help.
Q: What lubrication of the tractor require?
A: there are different oil holes for the engine oil ,fuel ,gearbox ,lifting.
Q: What type of three-point linkage does the tractor have?
A: The tractor has a Category 1 three-point linkage
Q: How much fuel does the tractor use?
A: Approximately 5 - 7 litres per hour, depending on engine capacity, speed, load, etc.
Please review the specifications page for more information.
Q: What speed and power does the PTO deliver?
A: The PTO has single 720 RPM or dual speeds: 540 / 1000 RPM.
Q: What type of brakes does the tractor have?
A: Drum Brakes on the rear wheels,or air brake.
