N700 Fabric Air Permeability Tester
Fabric Air Permeability Tester
Standards:
GB/T 5453, ISO 9237, ASTM D 737, BS 5636, GB 6031-85, GB 6529-86, GB 8170-87
Function:
To test the gas transmission rate of various textiles, including household textile, industrial textile, non-woven fabrics and other materials such as sponge, paper etc.
Application:
*Household textile and industrial textile
*Non-woven fabrics, sponge, paper, etc
Working principle
Keeping a pressure difference, test the flow volume of gas vertically penetrating the test area of sample in a certain period of time, so as to calculate the gas transmission rate.
Techinical parameter:
Test range | 0~20000mm/s |
Test accuracy | 1mm/s |
Pressure range | 0.1~500Pa |
Test area | 5cm2, 20cm2, 50cm2, 100cm2 |
Sample thickness | ≤10mm |
Features:
1. Pressure adjustable; auto measure, auto calculate.
2. After testing for continuous 10 times, auto calculate standard deviation and confidence interval.
3. Touch screen, voice feedback.
4. Can retrieve 10 history record entries; printing function, built-in printer.
5. Easy and simple to operate.
6. Dynamic display of data, clear to see.
7. Support unit conversion.
After sale Service:
1. 2 years coverage
2. Speedy reply, 12hrs response to customer questions
3. Software free update
4. Minor maintenance ---parts ship within 24 hrs
5. Major maintenance---Technical will be sent within 15 days
6. Free inhouse training for customer operator
