Kiya Lighting p3 p4 p5 Indoor Full Color Advertising Led Video Wall

Name: Kiya Lighting p3 p4 p5 Indoor Full Color Advertising Led Video Wall
Brand: KIYA
SKU: 102366849
Availability: InStock

US$ 850 - 1,050 MOQ: 8 Square Meters

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

KIYA

Model Number:

K-P4

Guangzhou Kiya Lighting Business Department

Payment & Shipping

Payment Methods:

Port of Shipment:

Huangpu

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name KIYA

Model Number K-P4

Usage Indoor

Tube Chip Color Full Color

Display Function Video

Pixels Other, 4mm

Screen Dimension Customized

Product Description

Kiya Lighting p3 p4 p5 indoor full color advertising led video wall

Pixel	Dot Pitch	4mm
	Pixel Configure	1R1G1B SMD 3IN1
	Pixel/SQM	62500Pixel/m²
LED Lamp	LED TYPE	SMD 2121
	Chip Brand	EPISTAR
	Wavelength & Brightness	Red:620-625nm;>270mcdGreen:520-525nm;>550mcd Blue:470-475nm;>90mcd
Module	Module Resolution	32Pixel * 32Pixel
	Drive Mode	Constant Current Drive
	Scanning Method	1/16Scanning
	Module Dimension	128mm(Width)x128mm(Height)
	Drive IC	MBI5024(Or other Similar IC)
	LED & Drive Composition	Light-Drive Combo
	Refresh Rate	>1000HZ
Cabinet	Cabinet Thickness	100mm
	Cabinet Construction	Normal Standard Cabinet
	Cabinet Assembly	Connecting Sheet
	Cabinet Color(Front/Back)	Black,Grey
	Aviation Plug	wp20
	Maintenance Mode	Back Maintenance
	Cabinet Material	Spcc1.
	Cabinet Dimension	5120X5120X100mm
	Module QTY	5(Width)X5(Height)
	Power Supply	China Power Supply
LED Screen	Viewing Angle	Horizontal : 120 ° Vertical: 120 °
	Brightness	>3000cd/m²
	Best Viewing Distance	4~20m
	LED Life	100,000Hours
	Maximum Power	1200w/m²
	Average Power	400w/m²
	Input Voltage	220V±10% Or 110V±10%
	Operation Environment	Temperature: -20°C~60°C; Humidity: 10%~95%
	Protection Grade	IP 30
	LED Screen Weight	30kg/m2
