P10 Rgb Led Module Screen Display Module

P10 Rgb Led Module Screen Display Module thumbnail-1
P10 Rgb Led Module Screen Display Module thumbnail-2
P10 Rgb Led Module Screen Display Module thumbnail-3
P10 Rgb Led Module Screen Display Module thumbnail-4
P10 Rgb Led Module Screen Display Module thumbnail-5
P10 Rgb Led Module Screen Display Module photo-1
P10 Rgb Led Module Screen Display Module photo-2
P10 Rgb Led Module Screen Display Module photo-3
P10 Rgb Led Module Screen Display Module photo-4
P10 Rgb Led Module Screen Display Module photo-5
US$ 13 - 18 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
MPLED
Model Number:
MI Series
Contact Supplier Request Quote Chat Now
Shenzhen MP LED Technology Co., Ltd.
Gold Verified Supplier
5Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name MPLED
Model Number MI Series
Usage Outdoor
Tube Chip Color Full Color
Display Function Video
Pixels 10mm
Screen Dimension 160mm x 160mm (based on pixel pitch)

                                     p10 rgb led module screen display module

Product Description

p10 rgb led module Advantage:

1. High Contrast ratio: 4000:1, high definition
This is a very high level to ensure a vivid image of our LED display screen system.
2. First-class LED chip:
Supplied by high strictly selected LED
3.High brightness and perfect uniformity.
7500cd per square above, clearly visible in direct sunlight,
4. Clear vivid image quality:
Perfect color blending and comfortable visual effect
5. Easy Installation & operation:
user friendly software for an easy interface to operate the LED system
6. Easy maintenance:
Front and rear cabinet access maintenance

7.Waterproof IP65

8. CE and RoHS approval
9. 24 months warranty and life long free tech-support
10. Available models: P6, P8, P10, P13,P16

p10 rgb led module screen display modulep10 rgb led module screen display module

p10 rgb led module screen display modulep10 rgb led module screen display module

Besides, MPLED provided various type of led display modules, with high quality and very competitive Price. The main series we have are as below:



1. Indoor UHD Full-color LED Module, like P1.25, P1.5, P1.9, P2.5, P3, P4, with black SMD.



2. Indoor HD Full-color LED Module, like P4.81, P5, P5.33, P6, P6.25, P7.62, P10, P12. both white led and     black led available, and magnetic front service module available as required.



3. Outdoor DIP 346 LED modules, with high brightness and waterproof. like P8, P10, P16.



4. Outdoor DIP 3-IN-1 LED modules, it has a very large viewin angle as 140 degree horizontally and 120 degree vertically. Higher brightness and more stable for long time outdoor use than SMD series. P6, P8, P10, P13.33.



5. Outdoor SMD LED modules. P6, P8, P10



6. Indoor and outdoor Single color and dual color Text led display





p10 rgb led module screen display module






Specifications
 Item Specification
Pixel Pitch 10mm
Pixel Configuration 1R1G1B
LED Type DIP346
Module Size 160mm x 160mm
Module Resolution 16dots x 16dots
Module Weight 0.45 KG
Grey Scale 16 bit
Refresh Rate >1920Hz
Scan Type 1/4 Scan
Brightness 700cd/m2 or 7500 nits
Viewing Angle(Horizontal/Vertical) 140/140 degree
AC Input Voltage 110-240V
AC Input Frequency 50/60 Hz
Power Consumption(Max./Ave.) 800/240W/m2
Storage Temperature -40 ~ +60 degree
Operation Temperature -40 ~ + 50 degree
IP Rating IP65
Lifetime at 50% brightness 100,000 hours
Control Distance     CAT5 cable:<100 m; Single mode fiber:<10 km
Signal Input Format                AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI
 Operating system   Windows (2000/XP/Vista/7)
 Control System Nova/Linsn/XIXUN/LUMEN
Application

 Application of p10 rgb led module screen display module:

widely used in venues such as banks, stock exchange centers, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, city squares, courts, schools, restaurants etc;



p10 rgb led module screen display module

Successful Projects

 p10 rgb led module screen display module

Company Information

p10 rgb led module screen display module

p10 rgb led module screen display module

FAQ

1. May I know the Minimum order for your LED Module?

1 pcs.



2. Can you provide door-to-door service?

No matter the shipping way(by express, by air or by sea) you choose, we will hand over the cargos to you safely and in time.



3. How long time I can get the cargos after placing the order ?

For modules, only 3-5 working days



4. May I know the package details?

For our product, generally we can provide you package by Plywood case,Flight case or carton case.

Carton is the standard package if no special requirements, and it's free.
