XF-V Vacuum Loader /Automatic Powder Vacuum Feeder
I. Characteristic:
The machine is well designed and produced, consisted of vacuum pump (non-oil & non-water), stainless-steel-made product sucking mouth, feeding tube, cloth filter (or 316 stainless steel filter), vibration cleaner (or compressed air blower), vacuum product hopper and product level control system. There are some different between when machine combined with packaging machine, pellet pressing machine and mixing machine respectively. Please advise your request when ordering.
II.Technical Parameter:
Lift Capacity |
3m³/h, 5m³/h |
Lifting Height(mm) |
1800mm from floor, 2300mm from floor |
Product Cabinet Cubage |
230L |
Product Cabinet Dimension |
860×900×1100mm |
Machine Power |
930W 1700W |
Power |
1.5-4Kw |
Power Supply |
380/220V 50-60Hz |
Weight |
130Kg 160Kg |
Packaging & Transportation:
Outer package: standard exported wooden case or according to customers’ requirement.
Inner package: stretch film
Transport by ship, by plane or by land.
XINGFEIPACK
------ One Brand Made in China and Moving Towards the World
Shanghai Xingfei Packaging Machinery Co., Ltd. is a professional manufacturer engaged in the research and development of packaging machinery and food machinery, and we are a member of the Chinese Food and Packaging Machinery Industrial Association.
