90 Degrees AC Analog Panel Meter Ammeter/voltmeter
Negotiable
MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Maxwel
Model Number:
DE-96, DE-72,DE-48
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ISO Certified Analog Current Panel MeterNegotiableMOQ: 50 Pieces -
Electromagnetic Instrument AC Current Meter 50A-100ANegotiableMOQ: 50 Pieces
-
Rectifier Instrument 0-50A AC Analog Panel MeterNegotiableMOQ: 50 Pieces
-
96x96 AC Analog Ammeter 0-20A in a Carton of 50PCSNegotiableMOQ: 50 Pieces
-
72x72 AC Analog Panel Meter 50-100A in a Carton of 100PCSNegotiableMOQ: 50 Pieces
Place of Origin
Zhejiang, China
Brand Name
Maxwel
Model Number
DE-96, DE-72,DE-48
Display Type
Analog Only
Measuring Range
0-1000A
Accuracy Class
1.5
Supply Voltage
220V
Operating Temperature
-25℃~40℃
Dimensions
48*48,72*72,96*96(mm )
Specifications
1.90 degrees AC analog panel meter2.Used with transformer
3.Various types for selection
4.Good quality
5.Competitive price
90 degrees AC analog panel meter ammeter/voltmeter
Specification:
Model: DE-T96, DE-T72, DE-T48, DE-C96, DE-C72, DE-C48
Accuracy: Class 1.5
Specs: 0.1A,0.5A,1A,1.5A,3A,5A,7.5A,10A,20A,25A,30A,50A,75, 100A(use Ext. CT 5A)
Note: For 60/75/100A direct meter, the class in 2.5.
Advantage: The scale can be easily changed without opening the front frame so that the class will not be influenced.
| Moving Iron type AC analog meter 90 degrees | |
| Nominal Size | 96×96, 80 x 80,72×72, 48×48 |
| Accuracy | 1.5, 2.5 (48 x 48 ) |
| Ammeter through current | 0.1A 0.5A 1A 1.5A 3A 4A 5A 10A 15A 20A 25A 30A 40A 50A 60A 75A 100A |
| Voltmeter through voltage | 30V 50V 75V 100V 120V 150V 200V 250V 300V 400V 450 500V 600V |
| Overload rate of ammeter | 1. non-overload; 2. 1.2 times ; 3. 2 times; 4. 5 times |
| Overload rate of voltmeter | 1.non-overload; 2. 1.2 times |
| Model | Unit | A | B | C | D | E | F |
| DE-96 | mm | 96 | 92 | 90 | 5.5 | 65 | 43 |
| DE-72 | mm | 72 | 68 | 66 | 5.5 | 65 | 43 |
| DE-48 | mm | 48 | 44 | 42 | 5.5 | 65 | 43 |
