CO2 Non-metal Laser Engraving Cutting Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Laser Type:
CO2
Place of Origin:
Guangdong, China
Brand Name:
Hailei
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CO2 Jewellery Laser Cutting Engraving MachineNegotiableMOQ: 1 Set -
Ceramic Plate Optical Fiber Laser Engraving MachineUS$ 10,000 - 18,000MOQ: 1 Set
-
Guns Fiber Laser Engraving Machine ,laser Marking MachineUS$ 12,000 - 18,000MOQ: 1 Set
-
Mini Gold and Sliver Jewellery Cnc Fiber Laser Engraving MachineUS$ 5,000 - 18,000MOQ: 1 Set
-
Portable Steenless Steel Tags Laser Engraving MachineUS$ 10,000 - 18,000MOQ: 1 Set
Laser Type
CO2
Place of Origin
Guangdong, China
Brand Name
Hailei
Model Number
HL-CO2-10w/30/50W/100w
Specifications
1:we are manufacture ,so low price2:long service life
3:stable quality
4:no consumables
produce introduce
1 CO2 engraving the sea radium laser CO2 engraving machine one kind less power, lower prices, mark designed specifically for ceramic products.
2 CTI vibration lens and F-θ lens, application the U.S. synrad carbon dioxide laser, stable performance, compact size.
3 The system is simple, fully computerized production, flexible to change. Independent development HLLaser engraving software, using WINDOWS interface, compatible with a variety of graphics editing software output file CORELDRAW, AUTOCAD, PHOTOSHOP, can be a variety of graphics, text and bar code engraving, and supports a variety of commonly used graphics file formats.
4 CO2 laser engraving machine is often referred to as gas laser marking machine or carbon dioxide laser marking machine, CO2 laser wavelengths of infrared light band for 10.64um gas lasers, the use of CO2 gas filled discharge tube as a medium for producing laser, when high voltage electrodes, a glow discharge in the discharge tube, gas molecules can release laser, will enlarge the laser energy after the formation of the laser beam for material processing. Change the optical path of the laser beam automatic engraving by computer-controlled galvanometer.
4 CO2 laser engraving machine is often referred to as gas laser marking machine or carbon dioxide laser marking machine, CO2 laser wavelengths of infrared light band for 10.64um gas lasers, the use of CO2 gas filled discharge tube as a medium for producing laser, when high voltage electrodes, a glow discharge in the discharge tube, gas molecules can release laser, will enlarge the laser energy after the formation of the laser beam for material processing. Change the optical path of the laser beam automatic engraving by computer-controlled galvanometer.
Application
1 Polyurethane, such as: artificial leather, paint and other non-metal laser engraving standard.
2 Wood, paper, ceramics, the EP material non-metal laser landmarks such as: hangers.
3 ABS, acrylic, PC: non-metallic electrical enclosures, electronic products, such as laser engraving.
Glass: glass carved
2 Wood, paper, ceramics, the EP material non-metal laser landmarks such as: hangers.
3 ABS, acrylic, PC: non-metallic electrical enclosures, electronic products, such as laser engraving.
Glass: glass carved
technology parameters
| model | HL-CO2-10w/30w/50w/100w |
| max laser power | 100w |
| engraving depth | ≤8mm |
| min line width | 0.1mm |
| total power | ≤ 3.5kw |
| laser wavelength | 10.64um |
| laser repeated frequence | ≤ 50KHz |
| standard engraving range | 140mm×140mm |
| engraving line speed | ≤ 8000mm/s |
| min character | 0.4mm |
| repetead presition | ±0.01mm |
| power demand | 220v ± 10%/50Hz |
| light system | 800mm × 430mm × 1200mm |
| control system | 560mm× 660mm× 1000mm |
Note : welcome you to send samples to our company, we will be free to make samples for your selection or customized products.
