Portable CO2 Laser Cnc Engraving Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Laser Type:
CO2
Engraving Area:
110x110mm
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Small Cnc Fiber Laser Engraving Machine,laser Wood Engraving Machine PriceUS$ 12,000 - 18,000MOQ: 1 Set -
400w High Speed Key Board Laser Welding Machine PriceUS$ 8,000 - 12,000MOQ: 1 Set
-
Mini Fiber Two-dimensional Code Laser Marking MachineUS$ 3,500 - 7,500MOQ: 1 Set
-
20w Portable Fiber Laser Marking MachineUS$ 3,500 - 7,500MOQ: 1 Set
-
Portable Optical Ooi Fiber Laser Marking Machine/fiber Laser Marking Machine Price Ooi Laser Marking MachineUS$ 8,000 - 15,000MOQ: 1 Set
Condition
New
Laser Type
CO2
Engraving Area
110x110mm
Engraving Speed
12000mm/s
CNC or Not
Yes
Cooling Mode
Water Cooling
Applicable Material
Acrylic, Crytal, Glass, Leather, Metal, plastic
Graphic Format Supported
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Place of Origin
Guangdong, China
Brand Name
Hailei
Model Number
HL-CO2-50W
Dimension(L*W*H)
700x500x700mm
Certification
CE, ISO
After-sales Service Provided
Engineers available to service machinery overseas
produce introduce
1 HL-CO2-50W engraving the sea radium laser CO2 engraving machine one kind less power, lower prices, mark designed specifically for ceramic products.
2 CTI vibration lens and F-θ lens, application the U.S. synrad carbon dioxide laser, stable performance, compact size.
3 The system is simple, fully computerized production, flexible to change. Independent development HLLaser engraving software, using WINDOWS interface, compatible with a variety of graphics editing software output file CORELDRAW, AUTOCAD, PHOTOSHOP, can be a variety of graphics, text and bar code engraving, and supports a variety of commonly used graphics file formats.
4 CO2 laser engraving machine is often referred to as gas laser marking machine or carbon dioxide laser marking machine, CO2 laser wavelengths of infrared light band for 10.64um gas lasers, the use of CO2 gas filled discharge tube as a medium for producing laser, when high voltage electrodes, a glow discharge in the discharge tube, gas molecules can release laser, will enlarge the laser energy after the formation of the laser beam for material processing. Change the optical path of the laser beam automatic engraving by computer-controlled galvanometer.
4 CO2 laser engraving machine is often referred to as gas laser marking machine or carbon dioxide laser marking machine, CO2 laser wavelengths of infrared light band for 10.64um gas lasers, the use of CO2 gas filled discharge tube as a medium for producing laser, when high voltage electrodes, a glow discharge in the discharge tube, gas molecules can release laser, will enlarge the laser energy after the formation of the laser beam for material processing. Change the optical path of the laser beam automatic engraving by computer-controlled galvanometer.
Application
1 Polyurethane, such as: artificial leather, paint and other non-metal laser engraving standard.
2 Wood, paper, ceramics, the EP material non-metal laser landmarks such as: hangers.
3 ABS, acrylic, PC: non-metallic electrical enclosures, electronic products, such as laser engraving.
Glass: glass carved
2 Wood, paper, ceramics, the EP material non-metal laser landmarks such as: hangers.
3 ABS, acrylic, PC: non-metallic electrical enclosures, electronic products, such as laser engraving.
Glass: glass carved
technology parameters
| model | HL-CO2-50w |
| max laser power | 50w |
| engraving depth | ≤6mm |
| min line width | 0.1mm |
| total power | ≤ 2kw |
| laser wavelength | 10.64um |
| laser repeated frequence | ≤ 50KHz |
| standard engraving range | 140mm×140mm |
| engraving line speed | ≤ 8000mm/s |
| min character | 0.4mm |
| repetead presition | ±0.01mm |
| power demand | 220v ± 10%/50Hz |
| light system | 800mm × 430mm × 1200mm |
| control system | 560mm× 660mm× 1000mm |
Note : welcome you to send samples to our company, we will be free to make samples for your selection or customized products.
