small backhoes loader for sale

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

small backhoes loader for sale
1.rated loading:2.5 ton
2.small bachoe loader
3.1m3 bucket capacity
4.engine optional

Product Specification:

small backhoes loader for sale

Main Technical Specification
1 system pressure
load hydraulic system	18Mpa
dig hydraulic system	20Mpa
steering hydraulic system	12Mpa
2 system flow	120L /min
3 four-wheel drive, whole hydraulic system
4 total operating weight	7600kg
5 maximum speed	22Km/h
6 maximum gradient capacity	30 °

1 loading bucket capacity	1m3
2 rated loading	2500KG
3 maximum articulated height of bucket	3400(mm)
4 bucket discharge height	2795(mm)
5 bucket discharge distance	1048(mm)
6 loading lift capacity	25KN
7 bucket hydraulic translation function	yes
8 bucket lift time	6.8s
9 bucket lower time	2.5s
10 bucket discharge time	1.2s
11 maximum tractive force	39KN
12 maximum breakout force	38KN

1 back acter bucket capacity	0.3m3
2 backacter discharge height	3878(mm)
3 maximum digging depth	4080(mm)
4 maximum digging radius	5688(mm)
5 bucket slewing angle	190 °
6 bucket digging capacity	46KN
7 bucket stick digging capacity	31KN
