Home > Products > New Products > XCMG 30t Truck crane QY30K5-1

XCMG 30t Truck crane QY30K5-1

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 200 Set / Sets per Month
Port Any port in China
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	QY35K5-1 truck crane
Rated Loading Capacity	30t	Rated Lifting Moment	1025 kN.m
Max. Lifting Load	300000kg	Max. Lifting Height	48.7m
Place of Origin	Jiangsu, China	Brand Name	XCMG
After-sales Service Provided	Overseas third-party support available

Product Description

Specifications

XCMG Truck Crane (QY30K5-1)
1.Three axles,pilot
2.Shanghai (206KW) or Hangzhou (213KW)
3.Lenthening 5-section octagon boom

XCMG 30t Truck crane QY30K5-1

Our main products areas are XCMG Truck Mounted Crane and All Terrneain Crane, including QY8D QY12 QY16C QY16D QY20B QY25K QY25K5 QY30K5 QY40K QY50B QY50K QY60K QY70K QY80K QY100K QY130K, QAY25 QAY130 QAY160 QAY200 QAY240 QAY300

Main Technical Parameters

•The innovative jib system adopts embedded block, plug-in boom head and octagon jib, which has excellent lifting performance and safe and reliable lifting work.
•The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
•Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.
•The torque limiter adopts colorful LCD display, realizing the intelligence of the failure diagnosis. The precision is ahead of the industry.
•Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.
•The humanity design makes the cab and control cab more spacious, and easy to operate.
•Six unique manufacturing technologies ensure the high quality.
•Extend the lifting space and scope, greatly improving the lifting capacity of the front part.

Detailed Specifications as follows:

Dimension	Unit	QY30K5-I
Overall length	mm	12570
Overall width	mm	2500
Overall height	mm	3390
Weight
Total weight in travel	kg	32400
Front axle load	kg	7000
Rear axle load	kg	25400
Power
Engine model		SC8DK280Q3	WD615.329
Engine rated power	kW/(r/min)	206/2200	213/2200
Engine rated torque	N.m/(r/min)	1112/1400	1160/1400
Travel
Max. travel speed	km/h	80
Min. turning diameter	m	22
Min. ground clearance	mm	291
Approach angle	°	19
Departure angle	°	13
Max. grade ability	%	40
Fuel consumption for 100km	L	40
Main performance
Max. rated total lifting capacity	t	30
Min. rated working radius	mm	3000
Turning radius at turntable tail	m	3.065
Max. lifting torque	kN.m	1025
Base boom	m	10.6
Fully extended boom	m	40.4
Fully extended boom+ jib	m	48.7
Longitudinal outrigger span	m	5.85
Lateral outrigger span	m	6
Working speed
Boom luffing time	s	68
Boom full extension time	s	150
Max. swing speed	r/min	2.5
Max. speed of main winch (single rope) (no load)	m/min	120
Max. speed of aux. winch (single rope) (no load)	m/min	120

As a leading supplier in China,we can assure you best quality with most competitive price.

Also,we can supply you original factory products and welcome customers home and abroad.

Detailed contact information as follows:

We can also help you in Hydraulic system Design .
