ac dc magnetic contactor1.LC1 LP1 LE1 contactor
2. AC DC contactor
3. magnetic contactor
LC1-D ac contactor
1.LC1 LP1 LE1
2. AC DC contactor
3. schneider new and old type contactor
LC1-D series AC contactors is for using in the AC circuit up to the rated voltage 660V AC 50Hz or 60Hz, rated current 95A, to connect or disconnect and frequent start/stop/control the AC motor. They can be combined together with auxiliary contact group, air delayer, mechanical interlocking contactors and etc, to constitute delayer, reversible contactor or star-triangle starter. This contactor can also be organized into electromagnetic starter by combined with the thermal relay.
| contactor Type | LC1-09 | LC1-12 | LC1-18 | LC1-25 | LC1-32 | LC1-40 | LC1-50 | LC1-65 | LC1-80 | LC1-95 |
| Rated Insulation (V) | 660 | 660 | 660 | 660 | 660 | 660 | 660 | 660 | 660 | 660 |
| Conventional Thermal Current (A) | 20 | 25 | 32 | 40 | 50 | 60 | 75 | 80 | 110 | 125 |
| Rated operational current 380V/ac3 | 9 | 12 | 16 | 25 | 32 | 40 | 50 | 63 | 80 | 95 |
| Controlled power(kw) | 2.2 | 3 | 4 | 5.5 | 11 | 15 | 18.5 | 22 | 25 | |
| 4 | 5.5 | 7.5 | 11 | 18.5 | 22 | 30 | 37 | 45 | ||
| 4 | 5.5 | 9 | 11 | 22 | 25 | 37 | 45 | 45 | ||
| 4 | 5.5 | 9 | 11 | 22 | 30 | 37 | 45 | 45 | ||
| 5.5 | 7.5 | 10 | 15 | 30 | 33 | 37 | 45 | 45 | ||
| Install way | 1.use 2 scews 2. use 35mm installation rail | 1.use 3 scews 2. use 35mm or 75mm installation rail | ||||||||
1. Design Services-- Our team has experience in all fields relating to product design and development. If you have any needs for your new product or wish to make further improvements, we are here to offer our support.
2. Samples Procedure-- purchasing from a Chinese supplier, especially for the first time, is that when the goods arrive - it's not what you wanted. Our samples procedure takes away that worry completely!
3. Research & Development -- Research & Development is a key part of what we do, and what we offer to our clients
4. Quality Control-- includes regular and thorough inspections throughout the manufacturing process, eliminating the need to employ additional quality control inspectors.
5. After-sales-- Working closely with our customers we evaluate the success of our delivered product
With your valuable feedback we can begin to plan for better services.
The Reason Why Choose Us? contactor
(1) We have been supplying own label and branded Electrical products for more than 10 years with clients from the USA and Europe . contactor
(2) We have a professional in-house design team which can support you in all aspects of product design.
contactor
(3) We continuously assess and review our partners; ensuring we can always offer the up to the minute products, the most competitive prices and the best quality products to satisfy our clients requirements.
(4) Samples are always available for checking quality and can be dispatched to you very quickly.
(5) We have a stringent quality control system; including checks throughout the production process.
(6) All Our products have passed CE. contactor
(7) Our production capability can reach 2,000,000 pieces per month . contactor
Who Can We Supply? contactor
We have experience in supplying customers throughout the USA and Europe. Our client base ranges from distributers looking to promote ready products, through to start ups looking to bring a product to market and multinational retailers looking for high volume, quality products distributed globally. contactor
The Business Partner We Are Seeking For? contactor
We are always interested to hear from potential partners and we are keen to develop our business in the USA, Europe and Asia. We are especially eager to hear from interested parties with experience and a network in Electrical. contactor
