Specifications
CNC Leather Nesting Equipmentsoptimise the nesting of leather
make the best usage of leather
fasten the cutting process.
Ruizhou CNC Leather Nesting Equipments
Ruizhou CNC Leather Nesting Equipments are a supporting device for the use of leather cutting machine. In
case of order saturation and high pressure of machine production, nesting of leather, labeling and
recording typeset information can be done in advance. All data can be shared with the cutting machine
to achieve seamless joint, which ensures continuous operation of machines and provides guarantee to
the enterprise to achieve an orderly digital production management.
Technical Parameters
Available Model |
RP-3212 |
RP-2510 |
RP-1510 |
Working Area |
3200mm×1200mm |
2500mm×1200mm |
1500mm×1000mm |
Mat. hold-down method |
Vacuum based on cells |
||
Control System |
Ruizhou Leather Nesting System |
||
Interface |
Standard parallel port, serial port or network port |
||
Command System |
HP-GL and GP-GL compatible mode |
||
Control Panel |
LCD Display, Touch Button, Touch Screen |
||
Host Voltage |
AC 220 ± 10% |
||
Host Frequency |
50±1Hz ,60±1Hz |
||
Vacuum Voltage |
AC 380 ± 10% |
||
Vacuum Power |
7.5kw |
5.5kw |
3.8kw |
