Automatic Backwash Transformer Oil Filtration Machine

Name: Automatic Backwash Transformer Oil Filtration Machine
Brand: ASSEN
SKU: 102105535
Availability: InStock

Automatic Backwash Transformer Oil Filtration Machine thumbnail-1

Automatic Backwash Transformer Oil Filtration Machine thumbnail-2

Automatic Backwash Transformer Oil Filtration Machine thumbnail-3

Automatic Backwash Transformer Oil Filtration Machine thumbnail-4

Automatic Backwash Transformer Oil Filtration Machine thumbnail-5

Automatic Backwash Transformer Oil Filtration Machine thumbnail-6

Automatic Backwash Transformer Oil Filtration Machine photo-1

Automatic Backwash Transformer Oil Filtration Machine photo-2

Automatic Backwash Transformer Oil Filtration Machine photo-3

Automatic Backwash Transformer Oil Filtration Machine photo-4

Automatic Backwash Transformer Oil Filtration Machine photo-5

Automatic Backwash Transformer Oil Filtration Machine photo-6

US$ 8,500 - 15,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Flow:

3000LPH

Working Pressure:

0.4MPA

Contact Supplier Request Quote Chat Now

Chongqing Assen Power Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Flow 3000LPH

Working Pressure 0.4MPA

Place of Origin Chongqing, China

Brand Name ASSEN

Model Number ZYD-50

Usage Insulation Oil

Voltage 380V or as customer's needs

Power(W) 45KW

Dimension(L*W*H) 1750*1150*1650

Weight 850KG

Certification CE,ISO

After-sales Service Provided Engineers available to service machinery overseas

Automatic backwash transformer oil filtration machine

Product Application

ZYD Automatic backwash transformer oil filtration machine is mainly used to extend the lifetime of oils used in transformers, circuit breakers, mutual inductor, voltage regulators and switch gear, or to inject the insulating oil into the transformers. Equipped with regenerators, ASSEN transformer oil filtration machines can improve the effect of de-acid, de-color and remove dielectric and acid more effectively. The value of breakdown voltage will increase from 15KV to 75KV. The performance and lifetime of insulating oil will improve and extend awfully after purification and regeneration.

Product Features

1.To remove free, soluble water, carbon, free and dissolved gases and particulate matters from insulating oil effectively and rapidly.

2.Enhance the value of breakdown voltage greatly.

3.Easy handling and maintenance.

4.Inject oil into the transformers

5.Online work

6.Lower maintenance and replacement expenses

7.High efficiency and effectiveness

8.Available in mobile or stationary options.

9.Small size, light weight, low noise

10. Various sizes and configurations (alloy shield) available.

Product Description

Transformer oil filtration machine:

ZYD series Transformer oil filtration machine is manufactured according to standards, which go beyond Chinese legal criterion, dealing with almost insulation oil of power equipment more rapidly and effectively with the supporting of high vacuum and speed absorption. Thus the strength of insulation oil is much increased, and the dealing time has been shortened.

Transformer oil filtration machine 's Technical Data:

Parameters		Unit	ZYD-30	ZYD-50	ZYD-100	ZYD-150	ZYD-200	ZYD-250	ZYD-300
Flow		L/min	30	50	100	150	200	250	300
Working vacuum		MPa	0.08 ~ 0.099
Working Pressure		MPa	≤0.3
Breakdown Voltage		KV	≥75
Water Content		PPM	≤3
Gas Content		%	≤0.01
Impurity Size		μ	≤5
Temperature Range		°C	20 ~ 80
Power			Three Phase 50HZ380V(as per the customer's requirements)
Working Noise		dB(A)	75	75	75	80	80	80	80
Heating Power		kW	30	30	45	60	75	90	120
Total Power		kW	35.5	37.5	52.5	71.4	86.5	102.5	135
Inlet/Outlet		mm	φ25	φ32	φ42	φ50	φ50	φ60	φ60
Weight		kg	600	800	1050	1400	1800	2000	2200
Overall	Length	mm	1050	1100	1200	1450	1600	1800	1900
	Width	mm	750	800	950	950	1100	1200	1200
	Height	mm	1350	1400	1500	1650	1800	1900	1900

Structure Chart:

The oil technical data after treatment:

Gas content less than 0.1%
Impurity size less than 1μm without free carbon
Oil dielectric strength (breakdown voltage) more than 75KV
Acidity value less than 0.01 mgKOH/g
Dielectric loss factors at 90°C less than 0.001

Transformer oil filtration machine's Advantage:

Comparing with the single-stage type, this machine adopts the double stages vacuum system, which can improve the machines working vacuum value highly, so it can dewater, degas and remove the impurity more deeply and effectively. The dielectric value of treated oil is higher than 75 KV. It is very suitable for the large electric & insulation equipments.

Packaging & Shipping

Our Services

Your inquiry related to our products or prices will be replied in 24 hours.
Well-trained and experienced staffs to answer all your enquires in fluent English.
Professional service from well-trained and experienced staffs is customers’ best choice to secure good communication, on time delivery, reliable warranty etc.
OEM is available for Anern Products.
Protection of your sales area, ideas of design and all your private information.

Our Customers

FAQ

Q: How can we achieve drying without elevated heating of the insulation material for transformers?
A: Drying of insulation materials can be achieved at low temperature and low pressure levels. The pressure levels and temperature levels for drying vary for distinct material. At low pressure or under vacuum the rate of water vapour evaporation is accelerated if sufficient heat is provided to the insulation material. Thus we can achieve a good drying of insulating material if the material is suitably heated and subjected to vacuum.
