Conveyor belt for microsoft device use

FOB Price

USD $7 - $20 / Meter

600 Meters(Min.Order)

Supply Ability 10000 Meter / Meters per Month
Port Shanghai Port
Payment Terms:T/T L/C D/P D/A

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Type:	Slat Conveyor	Material:	Polyester
Material Feature:	Heat Resistant	Structure:	Belt Conveyor	Place of Origin:	Jiangsu, China
Brand Name:	AMC	Model Number:	AMC022806

Packaging Details

200 meters per roll , each roll wrapped on the rubber / wooden reel, covered with Anti-UV cloth / According to customer's requirements

Product Description

Specifications

Conveyor Belting
1. EP/NN80-630
2. Width: 300-2600mm
3. Best quality level in China

Conveyor belt for microsoft device use

1.No:AMC022806
2.Thickness: 3mm--50mm
3.Width: 300mm--2600mm
4.payment: L/C,T/T ,d/p,d/a
5.delivery:15 days,1x20ft container

TECHNICAL DATA(the bigest width we can produce is 2600mm)

Specification and technical data of rubber conveyor belt

Fabric type	Fabric structure		Fabric specs	Ply thickness	Strength(N/mm)				Cover thickness		width	length
	warp	weft		mm/ply	2ply	3ply	4ply	5ply	upper	lower	mm	m
polyester	polester	polyamine	EP80		160	240	320	400	1.5-12	0-4.5	400-2600	50-500
			EP100	1	200	300	400	500
			EP150	1.1	300	450	600	750
			EP200	1.2	400	600	800	1000			500-2600
			EP250	1.35	500	7500	1000	1250
			EP300	1.45	600	900	1200	1500
			EP350	1.6		1050	1400	1750			800-2600
			EP400	1.75			1600	2000			1000-2600
			EP500	1.9			2000	2500
			EP630	2.1			2400	3000

Adhesion and elongation of belt

Belt carcass	Adhesive strength		elongation
	Between plies(N/mm)	Between rubber and carcass	Longitudinal elongation at break%≥	Longitudinal elongation at reference load%≤
EP canvas	≥5	≥5	10	2.0

Technical data of cover rubber

Cover grade	Tensile strength ≥	Elongation ≥	Abrasion ≤	Change rate of tensile strength and elongation after aging
	MPa	%	mm³	%
RMA1	17	400	175	-25+25
RMA2	14	350	250	-25+25
Z	15	350	250	-25+25
Y	20	400	150	-25+25
X	25	400	120	-25+25
W	18	400	90	-25+25
