RZCAM-1209A Vacuum Absorb Cutting Machine

Name: RZCAM-1209A Vacuum Absorb Cutting Machine
Brand: Ruizhou
SKU: 102097563

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Ruizhou

Model Number:

RZCAM-1209A

Guangdong Ruizhou Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Ruizhou

Model Number RZCAM-1209A

Specifications

Vacuum Absorb Cutting Machine, good quality and reasonable price, widely used for paper pattern cutting, best cutting solution.

RZCAM-1209A Vacuum Absorb Cutting Machine

Vacuum Absorb Cutting Machine, good quality and reasonable price, widely used for paper pattern cutting, best cutting solution.

Features:

Application of self-developed built-in digital control system,imported American CPU and precise electronic components reach the technologically leading level at home and aborad in stability and operability.
Joint use of imported linear tracks and synchronous belt in the machine makes the cutting precision up to the zero error of shuttle origin completely.
LCD display and digital control interface facilitate operation.
Connectible to random CAD software,it is widely used in such industries as shoe-making,apparel,suitcases and bags.

Technological Specification

Technical Parameters	RZCAM-0906A	RZCAM-0609E	RZCAM-1209A	RZCAM-1512A
Working character	The computer operation can be turn off at the same time with cutting, data transfer can be finished fast, and can be operated continuously.
Cutting speed	600mm-900mm
Cutting thickness	≤2.0mm
Cutting materials	Red hard paper board, plastic board, white paper board, etc.
Pen quantity	Varied pen shape, setup of full and half knife.
Pen quantity	Varied pen shape, setup of full and half knife.
Applicable pen type	Common singing pen, oil pen and ball-point pen.
Measure to fixing paper	Vacuum Adsorption/ Static Adsorption.
Mechanical resolution	0.005mm
Software resolution	0.025mm,0.01mm,0.1mm optional
Interface of transmission	Standard parallel and serial interface.
Command	HP-GL and GP-GL compatible mode
Digital control panel	Liquid crystal display and touching button.
Transmission materials	Imported timing belt / straight line guide
Cutting area	620mm*910mm	620mm*910mm	920mm*1200mm	1200mm*1500mm
Working voltage	Alternating current 220v±10%,50Hz
Specification of fuse	6A
