Small Sand Washer
Part One: Products Presentation
1)Application of Small Sand Washer
- Small Sand washer is used for sand washing, separating, and cleaning in the construction of high speed road, high speed railway, hydroelectric project, public works and so on.
2)Features of Small Sand Washer
- Highly efficient and stable wheeled sand washer
- Simple and reasonable structure
- Little loss of the sand during the washing.
3)Working Principle of Small Sand Washer
- The electric motor runs slowly with the impellor after decelerated by the belt, decelerator and gears wheel. The sand and stone flow into washing launder from feeding launder, rolls with the impellor, and grinds each other. The impurity covering the sand is washing away. At the same time, add more water, the strong water flow will take away waste and some low-weight wastes from washing launder. Through the above process, the washing function is finished. The clean sand and stone is lift up by vane. When it goes up slowly, the water begins to drop through the mesh and fall back in the washing launder. On one hand, water is removed from the sand and stone; on the other hand, the water can be fully used. Finally, the sand and stone goes to the out launder from the rotary impellor to finish the washing task.
Part Two: Main Technical Parameters of Small Sand Wsher
Type |
Capacity(t/h) |
Return Sand Capacity(t/h) |
Power(kw) |
Weight(kg) |
XSD 2000 |
8-40 |
3-8 |
4 |
1900 |
XSD 2600 |
20-100 |
5-15 |
5.5 |
3500 |
XSD 2800 |
50-130 |
8-70 |
7.5 |
5100 |
XSD 3200 |
240-300 |
80-130 |
11 |
8800 |
XSD 3600 |
280-500 |
100-200 |
15 |
14200 |
Note: If the type is not what you need, please contact us and more other types are available.
Also, we are pleasure to special disign the flow chat of sand making production line for you.
Part Three: Image of Small Sand Washer
1) Small sand washer pictures
2) Small sand washer installation pictures
(1) Pre-sale Service:
- Suitable-design products and resonable price will be supplied to you to meet your need. We can also offer experiment to test the equipment that the customer need.
(2) After-sale Service:
- On the spot guidance for installation by our engineers, and the buyer is responsible for the expense. We have a perfect after-sales service system and team with professional.
1. Do you provide custom-made service?
- We are manufacturer, so the machine can be designed as your wish.
2. How is the machine price?
- We can provide the machine at the factory prices.
3. Capacity you need?
- We can offer the capacity from 8t/h-500t/h.
We Zhengzhou Weilite Machinery Equipment Co., Ltd is a manufacturer and exporter of mining machinery in China. Our main products are sand washer, briquette machine, dryer, crusher and so on. All of them are ISO9001:2000 confirmed. They are excellent quality and enjoy good reputation both in China and overseas. Welcome to visit and purchase from us!
Part Four: Contact Information
- Contact person: Shayne Wang
- Tel:+86 (0)371 86687769
- Website: /
Note
In order to give you the most suitable type of machine, please kindly inform us the following information:
1. What's the raw material?
2. Size of raw material;
3. Discharging size you want;
4. The processing capacity.
If you didn't get the suitable machine in this page, please email me your detailed requirement. We are the manufacturer with over 30 years working experience. We can help you in this matter.
