Help CenterTop Quality Belt Dryer Charcoal Briquette Dryer
Related Products
-
High Efficiency Professional Barbecue Charcoal Briquette DryerUS$ 4,000 - 158,700MOQ: 1 Set -
Top Quality Low Price Tunnel Dryer For Wood SawdustUS$ 8,000 - 230,000MOQ: 1 Set
-
2014 Top Quality Cement Slag Drying MachineUS$ 6,000 - 1,860,000MOQ: 1 Set
-
High Quality Cement Slag Dryer In Cement IndustryUS$ 6,000 - 1,860,000MOQ: 1 Set
-
High Quality Mini Rotary Drum Drying Machine For Coal Saw DustUS$ 4,500 - 950,000MOQ: 1 Set
Belt dryer charcoal briquette dryer is a highly efficient drying machine that specially design for coal and charcoal briquettes production lines. The drying products include for example coal briquette, charcoal briquettes, biomass pellet, wood chips and other lump or solid materials. Drying temperature is adjustable according to different raw materials so it has a vast application. It has the character of high drying efficiency, low broken rate, stable performance,etc.
Belt dryer charcoal briquete dryer working theory
Belt dryer charcoal briquette dryer is horizontal dryer with multi-section combination, this kind of dryer is mainly used for drying in humidity state when the intensity is not high pellet or ball. The length of a dryer is according to the humidity and the output of the material. Material feed from the top and run back and forth from the top down to the Discharge port at the bottom of the drying box.Drying time for 15% humidity coal briquettes is approximately 60-90 minutes, customer can adjust the conveyor speed according to the humidity requirement of the finished ball, belt speed is adjustable in order to get good quality final products.
Belt dryer charcoal briquette dryer application
Examples of Coal Briquette Dryer Applications
- briquettes production line
-pellet production line
-other solid / lump / chips material drying production line
Belt dryer charcoal briquette dryer technical data
Type |
WDH0.8x8m-3 |
WDH1x20m-3 |
WDH1.5x20m-3 |
WDH2x20m-3 |
WDH1.5x30m-5 |
Length(m) |
8 |
20 |
20 |
20 |
30 |
Layer |
3 |
3 |
3 |
3 |
5 |
Mesh Belt Width(m) |
0.8 |
1 |
1.5 |
2 |
1.5 |
Moisture before drying(%) |
8%-12% |
8%-12% |
8%-12% |
8%-12% |
8%-12% |
Moisture after dried(%) |
1%-3% |
1%-3% |
1%-3% |
1%-3% |
1%-3% |
Power(kw) |
3 |
2.2x3 |
3x3 |
4x3 |
5.5x5 |
Drying Temperature(°C) |
70-300 |
70-300 |
70-300 |
70-300 |
70-300 |
Capacity(T/H) |
1-2 |
10-15 |
20-30 |
35-50 |
55-60 |
We can design the machine fro you according to your requirments. If you need design service, pelase let us know your raw material moisture,your requirement on finished products moisture and capacity.Our professional engineer will give the best solution.
1). If any interest in our belt dryer charcoal briquette dryer, please feel free to contact me and let me know your requirement on capacity and material moisture before and after dried.
2). We are professional machine manufacturer, we will help to choose the most suitable machine for you.
3). Quality Commitment: Quality Warranty, Grantee Period: 1 year. Supply wearing parts with favorable price and long term after-sales service.
4). If you need, we will dispatch professional engineer for installation, trail and worker training.
Zhengzhou Weilite Machinery Equipment Co., Ltd is a manufacturer and exporter of machine for briquette production line in China. Our main products are crusher, dryer, mixer, briquette machine and so on. They are excellent quality and enjoy good reputation both in China and overseas. Welcome to visit and purchase from us!
1.What kind of material can be dried by the belt dryer charcoal briquette dryer?
- Answer: Nearly all kinds of lump and chips material can be dried by our machine such as wood chips, leaves, coal briquettes, charcoal briquettes, iron pellets, etc.
2.What kind of fuel can be used with the belt dryer charcoal briquette dryer?
- Answer: Diesel, natural gas, coal, wood chips and other kind of fuel are OK.
3.What's the drying temperature of the belt dryer charcoal briquette dryer?
- Answer:Drying temperature of the dryer is adjustable. It varies from 70 to 350 °C.
4.How long will the briquettes stay in the belt dryer charcoal briquette dryer?
- Answer:Normally the drying time will be about 50-150 minutes.
5.Is the belt speed adjustable?
- Answer: Yes, the belt speed is adjustable to make sure it can dry material with differnt moisture.
6.The Way of the belt clean
- Answer:Regarding to the belt clean system, for the first and second layers we will use mesh belt and for the third layer we will use belt without mesh to make sure material will drop to the bottom of the dryer. And there are some overhaul doors to clean the dryer bottom.
7.Does the Dryer have a thermal insulation? Do we need warm room?
- Yes, there is thermal insulation inside the dryer. If the running place is not very cold, it does not need a warm room.
If any interested in our belt dryer charcoal briquette dryer, please feel free to contact me.
