BONENS RIG42 High-power Resistor

BONENS RIG42 High-power Resistor thumbnail-1
BONENS RIG42 High-power Resistor photo-1
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
Bonens
Model Number:
RIG42 high power resistor
Contact Supplier Request Quote Chat Now
Sichuan Qixing Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Sichuan, China
Brand Name Bonens
Model Number RIG42 high power resistor
Type Variable Resistor
Technology Metal Alloy
Package Type Throught Hole
Resistance 1~500Ω
Resistance Tolerance ±5%
Rated Power 1~1000W
Temperature Coefficient ±300*10-6/℃
Operating Temperature -55℃~+165℃

Specifications

,high power resistor
2,10ohm--50ohms
3,RoHS compliant
4,RUV certification
5,free sample and high quality

BONENS RIG42 High-power Resistor

 •Products of special resistance and specifications are provided.

 •Products of special standing wave ratio should be given a clear indication in contracts.

 •Special requirements of standing wave ration is tested and chosen only for products of 50Ω.

•Products are corresponded to the standard of GB/T5729-94.

•Any special requirement is appreciated.



Electrical Characteristics

Range of nominal resistance: 1 ~500Ω

 Frequency range: 0~2GHz

 Insulation resistance: ≥ 1GΩ

 Resistance tolerance: ±5%

Standing wave ratio: 1.2~1.3

 Withstand voltage: 500V/1 mm (Substrate thickness)



Environment Characteristics

Rated power: 1~1000W (70°C)

 TCR: ±300×10-6/°C

Moisture proof (GJB306A-96-Method106): ΔR≤±5%R

 Test at low temperature (-55°C, 24h): ΔR≤±5%R

 Collision: ΔR≤±3%R

 Temperature range: -55°C~+165°C

 Temperature shock (-55°C/+125°C, 3 times): ΔR≤±5%R

 Vibration (10-500HZ, 0.75mm, 6h): ΔR≤±3%R, No mechanical damage

 Load life (96): ΔR≤±5%
