BONENS 3296P Multi Turn Cermet Potentiometer Trimmer Potentiometer 10K(a103)

BONENS 3296P Multi Turn Cermet Potentiometer Trimmer Potentiometer 10K(a103) thumbnail-1
BONENS 3296P Multi Turn Cermet Potentiometer Trimmer Potentiometer 10K(a103) photo-1
US$ 0.05 - 0.09 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Sichuan, China
Brand Name:
BONENS
Model Number:
3296P
Contact Supplier Request Quote Chat Now
Sichuan Qixing Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangdong ports
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Sichuan, China
Brand Name BONENS
Model Number 3296P
Type Trimming Potentiometer
Technology Cermet
Resistance 10 ~5M
Resistance Tolerance ±10%
Rated Power 0.5W
Max. Operating Voltage 640V
Operating Temperature -55 ~+125

Specifications

1,RoHS ISO compliant
2,multi-turn cermet trimmer
3,free sample
4,fast delivery
5.trial order welcomed

BONENS 3296P multi turn cermet potentiometer Trimmer Potentiometer 10K(a103)Electrical Characteristics


Range of nominal resistance: 10Ω~5MΩ

Resistance tolerance: ±10%

Terminal resistance: ≤±1%R or 2Ω

Contact resistance variation (CRV): ≤±1%R or 3Ω

Insulation resistance: ≥ 1GΩ (100V AC)

Withstand voltage: 640V (DC or AC peak value)

Effective electrical travel≥70% of mechanical travel



Environment Characteristics


Rated power: 0.5W ( 300V max)

Temperature range: -55°C~+125°C

TCR: ±250×10-6/°C

Collision (390m/S2, 4000 times): ΔR≤±1%R

Vibration (10-500HZ, 0.75mm, 6h): ΔR≤±1%R, ΔUab/Uac≤±2%R, Electrical break≤100μS

Temperature variation (-55°C/30min, +125°C/30min, 5 cycles): ΔR≤±2%R, ΔUab/Uac≤±2%R

Climate category (IEC68-2-2): ΔR≤± (5%R+0.1Ω), Insulation Resistance≥100MΩ

Electrical endurance (0.5W, 1000h): ΔR≤± (5%R+0.1Ω),CRV≤±3%R or 5Ω

Mechanical endurance (200 cycles): ΔR≤± (10%R+0.5Ω), CRV≤±3%R or 5Ω

Steady damp heat (IEC68-2-3, Ca, 96h): ΔR≤± (5%R+0.1Ω), Insulation Resistance≥100MΩ



Physical Characteristics



Total mechanical travel: 28±2  laps

Starting torque: ≤20mN.m

Stopper torque:≥50mN.m

Standard package: 50 pcs /tube



  BONENS 3296P multi turn cermet potentiometer Trimmer Potentiometer 10K(a103)
