Specifications
CO2 laser cutting rubber machine 12901.high precesion, high speed
2.CE ISO
fessional manufacture
Economic CO2 laser cutting rubber machine 1290
Packaging & DeliveryPackaging
Detail: plywood case
Delivery Detail: within 15 working days after we receive your deposit
Specifications
Non-metal Laser engraving machine 1290 80W
1.high precesion, high speed
2.CE ISO
fessional manufacture
Features
1. High Speed Laser Engraving Machine&Laser Cutting Machine adopts the new high-efficiency laser tube, the laser beam is more stable than the traditional type,and the life time of the laser tube can be over 10000 hours.
2. more scientific design and high-strength steel-frame structure , which increase the fuselage strength more than 40% to prevent the machine from distortion during long term work.
3. The humanized and modern appearance shows Ruofen’s consistent humanity idea, and it also makes the operation and maintenance quite easy.
4. Advanced DSP control system, professional motion control chip, consecutive high speed curve cutting and the shortest path selection function improve the working efficiency a lot.
5.With red light positioning device accurately indicates the location of the processing of the laser head, eliminate the trouble about manual positioning.
Applications
The series of machine is suitable to art gift,advertisement decoration,toy,electron element,cutting of template,paper product,stamp and other industries, such as bamboo,putamina of coconut,paper,plexiglass,acrylic,marble,jade,crystal.Also can cut acrylic sheet,
paper and so on.
Parameters
NO. | Model | BCJ-1290 |
1 | Laser medium | CO2 |
2 | Working area | 1200*900mm |
3 | Working table | Blade table(or honeycomb table, could add Motorized up-down working table) |
4 | Laser power | 100 W(80W,130W,150W) |
5 | Power Supply | 220V/50Hz, 110V/60Hz |
6 | Min line width | ≤0.15mm |
7 | Positon accuracy | 0.01mm |
8 | Repetition accuracy | 0.02mm |
10 | Guide rail | HIWIN linear square guide rail from Taiwan |
11 | Transmission method | Fulong belt from shanghai |
12 | Drive system | Leadshine driving system and stepper motor |
13 | Cooling system | Water-cooling |
14 | Control system | LEETRO controller |
15 | Software suppoeted | Coreldraw, Photoshop, AutoCAD, Tajima |
16 | Graphic format support | PLT, DXF, BMP, JPG ,AI and ect |
17 | Working environment | 0-45°C, |
18 | Operating Humidity | 5-95% |
19 | Recommended Spare Parts | Laser Tube and Lens(Suggest additional sets) |
20 | Optional Parts | USB Feature, Up-down work table, Red light pointer, Rotary System |
Machine pictures
Machine Parts
Samples
Our factory
Why choose us
1. At the same quality grade, our products' price is better.
2. At the same products' price level, our service is better
3.5-9 days delivery,guaranteed
4.Response within 12hours
5.Service hotlines in the USA and Europe
6.Environmental friendly packaging
7.12 international approvals
