Charcoal Grinder and Mixer Machine | Coal Grinding and Mixing machine | Charcoal Crushing machine
Introduction
The mix and grinding machine is used to grind the charcoal into powder and at the same time to mix the charcoal equally.
The machine is used to crusher the big charcoal briquettes into charcoal powder and at same time it can mix the charcoal powder equally.
The sidewall of the circular disk is made of the steel plate with the thickness of 6mm, which the bottom is 10mm steel plate.
The features of the Wheel grinding and mixing machine
This Series products of our company’s dedicated reducer gear after heat treatment, it with good transmission,
high safety coefficient, superior Performance and quality than general reducer on the market.
Wheel grinding and mixing machine parameters
Type |
PS100 |
PS120 |
PS150 |
PS160 |
PS180 |
PS200 |
PS250 |
PS300 |
Disc diameter mm |
1000 |
1200 |
1500 |
1600 |
1800 |
2000 |
2500 |
3000 |
|
Feeding amount (Kg) |
110 |
150 |
350 |
450 |
650 |
900 |
1500 |
2000 |
|
Mixing cycle (min) |
3-8 |
3-5 |
3-5 |
3-5 |
3-5 |
2-5 |
2-5 |
2-5 |
|
Capacity (t/h) |
1.5-2.5 |
1.5-3.0 |
7 |
9 |
13 |
18 |
30 |
40 |
|
Spindle speed (r/min) |
41 |
41 |
37 |
37 |
36.1 |
35 |
30 |
30 |
|
Power (Kw) |
5.5 |
7.5 |
15 |
18.5 |
22 |
22 |
30 |
37 |
|
Dimmension ( m) |
1*1*1.2 |
1.2*1.2*1.3 |
1.5*1.5*1.6 |
1.6*1.6*1.7 |
1.8*1.8*1.8 |
2*2*1.8 |
2.5*2.5*1.8 |
3*3*1.8 |
|
Weight ( t) |
1 |
1.2 |
2 |
2.5 |
3 |
3.5 |
4 |
4.6 |
wooden package and LCL loading and full container loading
Delivery Time |
Within 5-7 working days after receiving clients’ payment. |
Payment Terms |
T/T, L/C, D/P, D/A, Escrow, Paypal, Western Union |
Packing |
a. Machines are wrapped in plastic film first before packing, which is to avoid moisture on the sea. |
Quality Guarantee Terms |
Quality guarantee term is for one year. Malfunctions which are caused by machineself and quality will be responsible for our manufacturer. Other malfunctions which are caused by operation mistakes, man-made problems, etc will be responsible for clients-self. |
|
Service |
All produts purchased in our company are guaranteed to keep in good repair for two years. If quality problems happen in guarantee period, our company will maintain for free. a, Before sending the machine, we will test and adjust, so you can use directly when you get it. Additionally, our company provides technical support and fittings for life. After-sales service isn't restricted by time and we will solve your problems in time. If you are caught in some problems when using our products, welcome to contact us at any time. a, Any problems occur while using, professional advice will be offered. |
1.We are food machine, farm machine Manufacturer.
2.Alibaba Assessed Gold Supplier.
3.Inspected by the Inspection Institution of Bureau Veritas Certification.
4.100% QC inspection Before Shipment.
5.Best Quality & Best Service with Competitive price.
1, Are you manufacturer?
Yes, we are manufacturer with more than 15 years' experience.
2, Can you ship the machine to my address?
Yes, we could use DHL to express the machine. While transport cost will be higher. Also, it is suitable for the small models.
3, Where are you? Can we go to China and visit your factory?
Yes, of course. We are in Henan, China. Welcome to our factory.
4, Do you have manual with the machine?
Yes, of course. It is in English version.
5, Can you offer us the necessary paper to do the customs clearance?
Yes, of course. We will send you the commercial invoice, sales contract, packing list, bill of lading(FOB or CFR, CIF terms), insurance policy (if CIF terms), also CO if you need.
