| INTRODUCTION: | ||||||||||
|
SHENDA QZ-92CG equip with LED display, microcontroller programming, 120 line encoder positioning accuracy. Operating system with shortcut keys, easy to learn. | ||||||||||
|
ABB electrical control components, single rail slot working platform. Quick pressure paper hydraulic system, gear cutting structure. | ||||||||||
| THE SYSTEM OF COMPUTER: | ||||||||||
| 1.The displaying panel use 7.5 inch, you can adjust the color by yourself. | ||||||||||
|
2.They have the high quality colors(25600), their storage can reach 30 groups, every group have 108 cut, Its storage time can reach 300,000 hours. |
||||||||||
| 3.The multi-language operating interface, such as Chinese,English,Spanish... | ||||||||||
| 4.It has luminous shortcut key so as to ensure the high stability. | ||||||||||
| THE APPARATUSCONTROLLED SYSTEM: | ||||||||||
| 1. Adopts Switzerland ABB, German MULLER, Japan OMRON. | ||||||||||
| 2. Air pump is from TAIWAN HOUBANG. | ||||||||||
| THE PAPER PUSHER CONTROLLED SYSTEM: | ||||||||||
| 1.General lead screw: ABBA | ||||||||||
| 2.Single rail guide way: ABBA | ||||||||||
| THE HYDRAULIC SYSTEM: | ||||||||||
|
1. Adjustable-pressure single-hydraulic system (paper pressing by the hydraumatic), |
||||||||||
| bined valve from German, ISO approved hydraulic units. | ||||||||||
| THE SAFETY PROTECTED SYSTEM: | ||||||||||
|
1.Extensible and precise infrared protective device from Shanghai Zhonghu photocell Control which reaches CE standard. |
||||||||||
| 2. Blade-Replacement Device with safety and convenience. | ||||||||||
| 3. Air cushion and chromeplating platform of photoelectricity protective device. | ||||||||||
| 4. Underlay cutter frame. | ||||||||||
| 5. The closed paper pusher frame. | ||||||||||
| 6. Machine lock, safety bolting, the safety button and light grid. | ||||||||||
| 7.The driving cutting part uses gear. | ||||||||||
| THE ACCESSORY WITH MACHINE: | ||||||||||
| 1. Tool box: 1set | ||||||||||
| 2. Manual book | ||||||||||
| 3. OperationalCD | ||||||||||
| 4. Guarantee sheet(details in contract) | ||||||||||
| MAIN SPECIFICATION: | ||||||||||
| MODEL | QZ-92CG KS | |||||||||
| Cutting width(mm) | 920 | |||||||||
| Max.cutting height(mm) | 120 | |||||||||
| (Without auxiliary panel ) | ||||||||||
| Max.cutting length(mm) | 920 | |||||||||
| Main motor power(kw) | 3 | |||||||||
| Net weight(kg) | 2200 | |||||||||
| Width with sideway(mm) | 2120 | |||||||||
| Without sideway(mm) | 1980 | |||||||||
| Machine lenght | 2050 | |||||||||
| Machine height | 1560 | |||||||||
| Front table length(mm) | 690 | |||||||||
| Table height(mm) | 900 | |||||||||
| Clamp pressure min(dan/bs) | 150 | |||||||||
| Max(dan/bs) | 3500 | |||||||||
| Knife thickness(mm) | 12.7 | |||||||||
| Grinding reserve(mm) | 30 | |||||||||
| Without false clamp(mm) | 25 | |||||||||
| With false clamp(mm) | 90 | |||||||||
| Cutting speed(mm) | 45 | |||||||||
| Voltage(three-phase)(v) | 361-339 | |||||||||
| Packing size(L*W*H)(mm) | 2320*1420*1850 | |||||||||
|
TERMS OF PAYMENT: 30% to be paid as deposit before producing, balance before shipment |
||||||||||
|
THE DELIVERY TIME: Within 30 days after receipt of the deposit. (If we have no in stock) |
||||||||||
| PACKING:Wooden case | ||||||||||
|
The guarantee year is one year expect some consumptive parts, the machine should use correctly. |
||||||||||
|
If the buyer need the supplier go for debug or maintain the machine, the buyer should pay the cost of tickets, room and board, traffic |
||||||||||
| Spare parts for free | ||||||||||
| 1. Total are 2 knives, one is in the machine, the other is packaged in case. | ||||||||||
| 2. 10 PCS safety screws | ||||||||||
| 3. 15PCS air balls | ||||||||||
| 4. Red cutter line 5 PCS | ||||||||||
