Help CenterHigh Accuracy Pressure Transmitter With RS485
Related Products
Feature:
1. 4~20mA Long distance transmit
2. RS485RTUdigital Output
3. Multi point non-linearity correction.
4. Temperature compensation in the whole temperature range
5. Lcd display
Speicification:
Pressure range |
-0.1……~100MPa |
Pressure overload |
≤1.5X |
Pressure type |
Absolute pressure, Gauge pressure, Sealed pressure |
Accuracy |
±0.1% |
Long stability |
±0.1%F.S/year(Typic.), ±0.2%F.S/year(Max.) |
Zero temperature drift |
±0.01%F.S/℃ |
Span temperature drift |
±0.01%F.S/℃ |
Compensation temperature |
0~70℃, 0~50℃(range<35KPa) |
Operating temperature range |
-20~80℃ |
Storage temperature range |
-40~120℃ |
Power supply |
15~28VDC |
Output signal |
4~20mA( CD ) |
RS485 RTU | |
Pressure port |
M20X1.5or customized |
Housing material |
304 stainless steel |
Diaphragm material |
316L stainless steel |
Insulation resistance |
100MΩ,100VDC |
IP Grade |
IP65 |
