Specifications
Wide mesurement range :0~10KPa~2MpaT-O8 packaging technic
High reliability and stability
HT12 Piezoresistive Silicon Pressure Sensor
Description
HT12 is piezoresistive silicon pressure sensor, the main element is a diffused silicon with high stability.It utilizs TO-8 packaging technic.With high reliability,reliability and stability. It is used for air pressure measurement.
Features
Wide mesurement range :0~10KPa~2Mpa
High reliability and stability
T-O8 packaging technic
Applications
Air control system
biomedical instrument HVAC control
Aviation inspection
Electrical Data
Supply :1.5mADC Input impedance:3KΩ~6KΩ
Output impedance:2.5KΩ~6KΩ Insulation resistance:≥100MΩ/50VDC
Insulation voltage: 500VAC between the housing and electrical connection will not cause damage
