7" 10.4" 12.1" 15" 17" 19" Industrial Open Frame Monitor 15inch TFT LCD Touch Screen Quality Choice M

US$ 150 - 160 MOQ: 1 Piece

Key Specifications

Products Status:

Stock

Screen Size:

Other, 15"

Type:

Resistive

Shenzhen Delonghuale Electronic & Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Products Status Stock

Screen Size Other, 15"

Type Resistive

Interface Type D-Sub, USB, Other, D-Sub, USB, VGA AUDIO

Resolution 1024 x 768

Brand Name OEM

Model Number DL170A

Place of Origin Guangdong, China

Factory price! 15" open frame LCD Monitor (Industrial monitor) ,Hot Sale Recently!

Please take the opportunity!!!

1.Cheapest price with factory

2.High quality with best service

3.With A grade branded LCD panel

4.CE,FCC,CCC,ROHS,ISO9000

open frame tft monitor 15

specification

Parameters	Working Voltage:	DC 11.5V-15V
	Working Temperature:	-10°C~60°C
	Storage temperature	-10~60°C
	Input configuration:	2 channel of video input, 1 channel L/R audio input
	Screen size:	17 inches (4:3 diagonal)
	LCD cell life time	50000 Hrs
	Active area	337.92(H)*270.34(V)mm
	Driver element	a-Si TFT active matrix
	Resolutions:	1280(H)×RGB×1024(V) pixel
	Pixel pitch	0.264(H)*0.264(V)
	Pixel arrangment	RGB vertical stripe
	Display colors	16.2M
	Transmissive mode	normally white
	surface treatment	hard coating(3H),AG(Haze 25%)
	Brightness:	300cd/ m2
	Contrast:	500:1
	Response time	6ms
	Electronic consumption:	16.9W
	IR/FM Frequency	FM-88.9MHZ; IR-2.3MHZ/2.8MHZ
	TV channel parameters	VHF-L 48.25~170.00MHZ VHF-H 1700.00~450.00MHZ
	LCD Panel	NEW 17inch 4:3 panel, A+ grade
	View angle	65/65 L/R, 60/50 U/D
Functions	Full Function Touch Panel with PC
	Stand Optional
	VGA Port
	With automatic adjustment can optimize picture quality. As car monitor/TV, industrial, control and POS terminals
	The Highest Resolution is to 1920×1200
	Operation System is WIN9X, 2000, ME,CE/UNIX
Accessories	1pcs LCD Monitor
	1pcs Remote Controller
	1pcs Stand Shelf
	1pcs VGA Cable
	1pcs Instruction Manual
	1pcs AC/DC Power
	Some Screw for Fixing the Shelf
