Home > Products > Mini ITX Motherboard > Mainboard--Intel 855GM/852GM GMCH Built-in Intel Extreme Graphics With 266 MHz VGA Core

Mainboard--Intel 855GM/852GM GMCH Built-in Intel Extreme Graphics With 266 MHz VGA Core

FOB Price

Negotiable / Piece

100 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Intel 855GM/852GM GMCH built-in Intel Extreme Graphics with 266 MHz VGA core, 256-bit 3D engine and dynamic video memory .

Intel CLIA-8GMRT
Processor	on board Intel nPGA479 Pentium M or Celeron M CPU @ 533/400 MHz FSB
Chipset	Intel 855GM/852GM series (GM/GME) GMCH and 82801DB ICH4
System Memory	1 DDR266/333/400 DIMM socket Up to 1GB memory size
VGA	Intel 855GM/852GM GMCH built-in Intel Extreme Graphics with 266 MHz VGA core, 256-bit 3D engine and dynamic video memory
Expansion Slots	1 PCI
IDEOnboard IDE	2 X UltraDMA 133/100/66 Connectors
Onboard LAN	RTL8100BL 10/100 Mbps Fast Ethernet interface
Onboard Audio	ALC101 AC’97 Codec
Onboard I/O Connectors	2 USB connector for 4 additional USB 2.0 ports Front-panel audio connectors (mic-in and line-out) 1 LVDS connector port I IR connector port CPU FAN/Sys FAN 3 Serial port connector for a second com port
Back Panel I/O	1 PS2 mouse port 1 PS2 keyboard port 1 Parallel 1 RJ-45 LAN port 1 Serial port 2 USB 2.0 ports 1 VGA port 1 TV out port 3 Audio jacks: line-out, line-in and mic-in (Smart 5.1 Support)
BIOS	Award BIOS Ver6.0 4Mbit flash memory
Form Factor	Mini-ITX 170mm x 170mm
