HF150 Drilling Equipment With Two Wheels

HF150 Drilling Equipment With Two Wheels thumbnail-1
HF150 Drilling Equipment With Two Wheels photo-1
US$ 8,000 - 12,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Core Drilling Rig
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Zhengzhou Hanfa Prospecting Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Core Drilling Rig
Power Type Diesel
Place of Origin Henan, China
Brand Name Hanfa drilling equipment
Model Number HF150 drilling equipment
Usage Other, core drilling
Voltage 220V/380V
Power(W) 15kw
Dimension(L*W*H) 2.75*0.95*1.6m
Weight 910kg
Certification ISO CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

HF150 drilling equipment with two wheel



I.Introduction of drilling equipment HF150


>it can drill Max150m depth,Max 300mm drill diameter



2>it equip different drill bits to drill different stratum,such as sand,soil,clay,hard rock etc,high efficiency

3>Hydraulic system control and trailer type ,easy to operate and move,saving labor force

4>it can be used for drilling water well,geothermy well,soil sampling or mining sampling,geological prospecting etc,wide application

5>national inspection-free product,quality guarantee,it can be used at least 10 yrs without full repair;as well as we offer you one-year quality warranty of main machine



II. Technical parameter of drilling equipment HF150

Unity machine parameter

Drilling Depth

30--150m

Drilling Diameter

300-75mm

Drill rod caliber

50mm

Drilling angle

90°~75°

Drill weight (No include power)

910kg

Unity machine dimensions

2.75×0.95×1.6

Spindle

spindle speed

64,128,287,557r/min

Spindle stroke

 450mm

Hoist

Max.single line hoisting capacity

1600kg

Single line lifting speed

17,35,75,151r/min

Tightrope caliber

12.5mm

Tightrope cubic measure

35m

Hug floodgate caliber

245mm

Hug folldgate belt width

70mm

Distance between drill and hole

400mm

Mud pump

Type

Horizontal single urn twin-action

Displacement

170L/min

Diesle engine

s1105 18HP

Electric motor

Y160M—4 15kw 1440r/min

Maximum pressure

1.5Mpa

Work pressure

0.7Mpa

Water inlet caliber

40mm

Water to exit caliber

30mm

Triangle conveyer belt

B1728mm

















































































 HF150 drilling equipment with two wheels



HF150 drilling equipment with two wheels



 HF150 drilling equipment with two wheelsHF150 drilling equipment with two wheels
